The parameters available on the Output browser screen are identical to the front panel
display menus. Complete descriptions of these parameters are accessible using the
following cross references:
• SDI1 Video Output (see “1.1 SDI1 Video Out” on page 60 )
• SDI2 Video Out (see ““1.2 SDI2 Video Out” on page 60 )
• Fiber1 Video Out (see “2.1 Fiber1 Video Out” on page 61 )
• Fiber2 Video Out (see “2.2 Fiber2 Video Out” on page 61 )
• HDMI Video Out (see “3 HDMI Video Out” on page 61 )
• Component Out (see “4 Component Out” on page 61 )
• Composite Out (see “5 Composite Out” on page 61 )
• HDMI Audio Out4 (see “6 HDMI Audio Out” on page 61 )
• AES/EBU Audio Out (see “7 AES/EBU Audio Out” on page 61 )
• Analog Audio Out (see “8 Analog Audio Out” on page 62 )
• SDI1 3G Config (see “9.1 SDI1 3G Config” on page 62 )
• SDI2 3G Config (see “9.2 SDI2 3G Config” on page 62 )
• Fiber1 3G Config (see “10.1 Fiber1 3G Config” on page 62 )
• Fiber2 3G Config (see “10.2 Fiber2 3G Config” on page 62 )
Video 1 & 2 Screens
The Video 1 and 2 screens select the video and audio outputs that are routed to the FS2
rear panel, and controls the FS2’s video signal processing.
The parameters available on the Video 1 and 2 browser screens are identical to the front
panel display menus. Complete descriptions of these parameters are accessible using the
following cross references:
• Video Input (see “1 Video Input” on page 63 )
• Output Format (see “2 Output Format” on page 63 )
• Video Output Mode (see “3 Video Output Mode” on page 64 )
• Background Fill (see “4 Background Fill” on page 64 )
