FS2 v2.1r1 www.aja.com 61
2.1 Fiber1 Video
Out
This parameter selects which video processor output is sent to the optional Fiber1
output, and is similar to
“1.1 SDI1 Video Out” on page 60 . The default is to send the output
of Processor 1 to Fiber1 Out.
2.2 Fiber2 Video
Out
This parameter selects which video processor output is sent to the optional Fiber2
output, and is similar to
“1.1 SDI1 Video Out” on page 60 . The default is to send the output
of Processor 2 to the Fiber2 Output.
3 HDMI Video Out
This parameter selects which video processor output is sent to the HDMI output.
4 Component Out
This parameter selects the video processor output to be sent out the Component analog
output.
5 Composite Out
This parameter selects the video processor output to be sent out the Composite analog
output. If an HD output is sent to the Composite Output, a separate Downconverter
dedicated to the Composite Output will provide an SD output.
6 HDMI Audio Out
This parameter selects which audio processor output channels (1–8 or 9–16) are
embedded in the HDMI output. The Audio Processor associated with the selected Video
Processor for the HDMI output is used as the audio source (Video Proc 1 = Audio Proc 1,
Video Proc 2 = Audio Proc 2); this parameter selects which channels of that source are
embedded.
7 AES/EBU Audio
Out
This parameter selects the audio processor output to be sent out the AES/EBU digital
audio output.
Processor1 (default)
Processor2
Proc1+Proc2 Sends the output of Processor 1 to the Fiber1 output.
Sends the output of Processor 2 to the Fiber1 output.
Sends multiplexed Proc 1 & 2 to the Fiber1 output (Dual Stream 3G).
Processor1
Processor2 (default)
Proc1+Proc2 Sends the output of Processor 1 to the Fiber2 output.
Sends the output of Processor 2 to the Fiber2 output.
Sends multiplexed Proc 1 & 2 to the Fiber2 output (Dual Stream 3G).
Processor1 (default)
Processor2 Sends the output of Processor 1 to the HDMI output.
Sends the output of Processor 2 to the HDMI output.
Processor1 (default)
Processor2 Sends the output of Processor 1 to the Component output.
Sends the output of Processor 2 to the Component output.
Processor1 (default)
Processor2 Sends the output of Processor 1 to the Composite output.
Sends the output of Processor 2 to the Composite output.
Channels 1-8 (default)
Channels 9-16 Selects audio channels 1-8 to embed in the HDMI output.
Selects audio channels 9-16 to embed in the HDMI output.
Processor1 (default)
Processor2 Selects Audio Processor 1 output to send to the AES/EBU output.
Selects Audio Processor 2 output to send to the AES/EBU output.
