FS2 v2.1r1 www.aja.com 46
S.9 Dolby Status
This menu shows the FS2's Dolby Decoder settings.
S.10 Dolby Framer
Status
This menu shows the current Dolby Framer status for Processors 1 and 2.
S.11 System Name
This menu shows the FS2's System Name, IP address and mask, and version number.
REMOTE Menu Group
The REMOTE Menu Group lets you set up how you want the FS2 to be controlled. Control
options include the front panel, a remote computer running a browser, and GPI inputs
and outputs.
NOTE: The Remote Menu Group parameters available on the front panel interact with the browser
parameters available on an attached computer, and vice versa. For example, the Remote
Control parameter can only be changed from the front panel, and when set to Local Only will
deactivate all browser remote control parameters.
1 Remote Control
This parameter determines whether the FS2panel responds to controls locally from the
front panel, from a network attached computer with a web browser, or both. The
selected mode is indicated by the color of the REMOTE LED.
Display Description
DolbyDec Status
DolBDecM Status
DolBDAx0 Status
DolBDAxM Status
Dolby Status: Unknown, NotInstl, DolbyE, DlbyDgtl or PCM.
Dolby Decoder Mode setting: Auto, Dolby E or Dolby D.
Decoder Aux Out setting: Program1 (through) Program8.
Decoder Aux Mode setting: Lt/Rt, Lo/Ro, Mono, Mute.
Display Description
Aud1 State Status
Frm1 Status
Aud2 State Status
Frm2 Status
Processor 1 Audio Dolby E Framer sync: Off, On, or Offset. For
On or Offset, shows the selected channel pair.
Processor 1 Audio Dolby E Framer: Locked or Unlocked.
Processor 2 Audio Dolby E Framer sync: Off, On, or Offset. For
On or Offset, shows the selected channel pair.
Processor 2 Audio Dolby E Framer: Locked or Unlocked.
Display Description
System Name
IP addr value
IP Mask value
Version value
Displays the System Name as set in Config menu 1.
Shows the FS2’s IP address.
Shows the FS2’s IP mask.
Shows the FS2’s software version number.
Local + Remote (default)
Local Only
Remote Only
Control the FS2 from the front panel, a remote control panel, or a
network-attached browser. The REMOTE LED lights amber.
Control the FS2 only from the front panel (browsers cannot
change parameters). The REMOTE LED lights green.
Control the FS2 only from a network attached browser or remote
control panel. The REMOTE LED lights red.
