FS2 v2.1r1 www.aja.com 95
Presets Screen
The Presets screen allows you to save FS2 Preset Configurations into 40 separate memory
registers and recall the presets whenever needed. This screen also includes Export and
Import functions that allow exporting one or all FS2 presets to your computer as files and
importing exported preset files from your computer. A displayed message indicates
successful or failed saves, recalls, exports, and imports.
Presets Screen
Controls
Factory Preset Factory Preset recalls all editable video and audio parameters to their factory default
settings. Individual presets, user preferences, and Network settings, such as the IP
Address, are not affected.
Recall The Recall buttons recall saved FS2 preset configurations.
Store The Store buttons let you save the current FS2 configuration into the preset register with
the associated name and number. A preset is a set of all System, Video, Audio, and Output
parameters as they were set at the time the preset was stored. Only editable parameters
are saved in the presets. Non-editable parameters are
not saved.
To change a preset name, click in the name's text field and type a new name.
Caution!
When you recall a Preset Configuration, the recalled preset immediately replaces the
system’s existing configuration. All previous settings are lost unless you have
previously stored them in another preset configuration or an exported file.
