FS2 v2.1r1
www.aja.com
103
SNMP Configuration Parameters
4.0 SNMP Enable
The SNMP Enable parameter turns ON and OFF all SNMP messaging between the FS2 and
an external client.
4.1 SNMP Trap
Destination 1
This parameter determines the SNMP Trap Destination IP address where trap messages
issued by the FS2 will be sent. This parameter is available only if parameter 4.0 SNMP
Enable is set to On.
4.2 SNMP Trap
Port 1
This parameter determines the SNMP Trap Port 1 used for sending destination #1 trap
messages. UDP Port 162 is the default used for SNMP trap messages. However, if this port
is being used by another protocol or service, you can change the setting by modifying
this parameter. This parameter is available only if parameter 4.0 SNMP Enable is set to On.
NOTE:
The SNMP Trap Port number does not blink when changed (as does the Trap Destination IP
address); if you change the port number and exit the parameter, the port changes
immediately to the new value.
4.3 SNMP Trap
Destination 2
This parameter determines the secondary SNMP Trap Destination IP address where trap
messages issued by the FS2 will be sent (if desired). This parameter is similar to 4.1 Trap
Destination 1 above. Default is 192.168.0.3
4.4 SNMP Trap
Port 2
This parameter determines the SNMP Trap Port used for sending destination #2 trap
messages, similar to 4.2 SNMP Trap Port 1 above. Default is 162.
If you need to revert to the previous setting (undo changes), push SELECT. If you want to
revert to the default value, hold down ADJUST for 4 seconds.
Disable
(default)
Enable 1
Enable Both
When set to Disable, the FS2 will not issue SNMP trap messages.
When set to Enable 1, the FS2 issues SNMP trap messages to Trap
Destination 1 (parameter 4.1) and as defined in the MIB.
When set to Enable Both, the FS2 issues SNMP trap messages to Trap
Destination 1 and 2 (parameters 4.1 and 4.3) and as defined in the
MIB.
IP Address
Set the desired IP address where traps will be sent (usually a client
on your LAN). Default: 192.168.0.3
Variable
Select a UDP port for sending FS2 trap messages. Default: 162
