FS2 v2.1r1 www.aja.com 14
Up, down, or cross conversion is done with very high quality scalers. De-interlacing is
performed with high quality motion-adaptive processing including diagonal filters. The
Processing Amplifier and Color Correctors support video signal adjustment with
standard Proc Amp controls and RGB-style color correction.
The keyers in each video processor can operate in several modes:
• Add a background for HD sidebar upconversion. The background can be Black, a user-
configurable matte, video from the other video processor (which itself can be
upconverted), or a video still (future firmware release) from the internal stillstore.
• Add a video/key graphic from the internal graphic stillstore (future firmware release)
• Combine the two video processors in various ways, such as creating a live “over-the-
shoulder” key.
The Video Processors can also be used as a still store and output full screen stills or test
patterns.
Audio Processors
The two audio processors accept analog, digital, or embedded audio inputs as chosen by
the input crosspoint matrix. Inputs can be selected from Embedded (SDI, Fiber, or HDMI),
AES, or Balanced Analog and full channel mapping supports any mixture of the inputs.
Each audio processor processes and outputs 16 channels. The output of each processor
can be embedded in its respective Video processor output (SDI, Fiber, or HDMI), or sent
to the AES or Balanced outputs. For 3G and Dual link Inputs, the Audio processors can
have access to all 32 channels.
In This Manual
Chapter 1: Introduction provides an overview and a list of box contents.
Chapter 2: Controls, Indicators, and Connections describes controls, indicators, and
connections.
Chapter 3: Installation and Configuration provides complete instructions for installing
and configuring the FS2.
Chapter 4: Display Menus explains how to use the FS2 controls and display menus.
Chapter 5: Browser Control explains how to use the FS2 remotely via a web browser on a
network-attached computer.
Chapter 6: SNMP discusses FS2 support of SNMP.
Appendix A: Specifications presents a list of technical specifications for the product.
Appendix B: Pinouts explains the FS2 rear panel connector pinouts.
Appendix C: Safety & Compliance provides regulatory compliance statements,
advisories and warnings.
Index
