Rockwell Automation Publication GMC-RM003C-EN-P - September 2013
25
Kinetix 6000 and Kinetix 6200/6500 Drive Systems
Bulletin MPL Motor Performance Specifications with Kinetix 6200/6500 (400V-class) Drives
Rotary Motor
Speed, max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 6200/
Kinetix 6500
400V-class Drives
MPL-B1510V
8000
0.95
0.26 (2.3)
3.10
0.77 (6.8)
0.16
2094-BMP5-M
MPL-B1520U
7000
1.80
0.49 (4.3)
6.10
1.58 (13.9)
0.27
2094-BMP5-M
MPL-B1530U
7000
2.0
0.90 (8.0)
7.20
2.82 (24.9)
0.39
2094-BMP5-M
MPL-B210V
8000
1.75
0.55 (4.9)
5.80
1.52 (13.4)
0.37
2094-BMP5-M
MPL-B220T
6000
3.30
1.61 (14.2)
9.90
4.12 (36.4)
0.62
2094-BMP5-M
11.3
4.74 (41.9)
2094-BM01-M
MPL-B230P
5000
2.60
2.10 (18.6)
9.90
7.24 (64.0)
0.86
2094-BMP5-M
11.3
8.20 (73.0)
2094-BM01-M
MPL-B310P
5000
2.4
1.6 (14.1)
7.10
3.6 (32)
0.77
2094-BMP5-M
MPL-B320P
5000
4.0
2.7 (23.9)
9.90
5.9 (52.2)
1.5
2094-BMP5-M
4.5
3.10 (27)
14.0
8.2 (72.5)
2094-BM01-M
MPL-B330P
5000
4.0
2.7 (23.9)
9.90
6.8 (60.2)
1.8
2094-BMP5-M
6.1
4.18 (37)
19.0
11.1 (98)
2094-BM01-M
MPL-B420P
5000
6.3
4.74 (42)
21.6
13.1 (116)
1.9
2094-BM01-M
22.0
13.5 (119)
2094-BM02-M
MPL-B430P
5000
8.6
6.2 (54.9)
21.6
13.9 (123)
2.2
2094-BM01-M
9.2
6.55 (58)
32.0
19.8 (175)
2094-BM02-M
MPL-B4530F
3000
4.0
4.9 (43.3)
9.90
11.0 (97.3)
2.1
2094-BMP5-M
6.7
8.36 (74)
21.0
20.3 (180)
2094-BM01-M
MPL-B4530K
4000
8.6
7.1 (62.8)
21.6
15.1 (133)
2.6
2094-BM01-M
9.9
8.25 (73)
31.0
20.3 (179)
2094-BM02-M
MPL-B4540F
3000
8.6
9.5 (84.1)
21.6
20.9 (185)
2.6
2094-BM01-M
9.1
10.20 (90)
29.0
27.1 (240)
2094-BM02-M
MPL-B4560F
3000
8.6
10.5 (92.9)
21.6
22.7 (201)
3.2
2094-BM01-M
11.8
14.0 (124)
36.0
34.4 (304)
2094-BM02-M
MPL-B520K
4000
8.6
7.9 (69.9)
21.6
16.6 (147)
3.5
2094-BM01-M
11.5
10.7 (95)
33.0
23.2 (205)
2094-BM02-M
MPL-B540D
2000
8.6
15.8 (139)
21.6
37.9 (335)
3.4
2094-BM01-M
10.5
19.4 (172)
23.0
41.0 (362)
2094-BM02-M
MPL-B540K
4000
20.4
19.4 (171)
60.0
48.6 (430)
5.4
2094-BM03-M
MPL-B560F
3000
20.6
26.8 (237)
68.0
67.8 (600)
5.5
2094-BM03-M
MPL-B580F
3000
26.0
34.0 (300)
75.0
74.6 (660)
7.1
2094-BM03-M
94.0
87.0 (770)
2094-BM05-M
MPL-B580J
3800
30.0
31.7 (280)
75.0
67.0 (592)
7.9
2094-BM03-M
32.0
34.0 (301)
94.0
81.0 (716)
2094-BM05-M
MPL-B640F
3000
30.0
34.4 (304)
65.0
72.3 (640)
6.1
2094-BM03-M
32.0
36.7 (325)
2094-BM05-M
MPL-B660F
3000
38.5
48.0 (425)
96.0
101 (895)
6.1
2094-BM05-M
MPL-B680D
2000
30.0
55.4 (490)
75.0
125 (1105)
9.3
2094-BM03-M
34.0
62.8 (556)
94.0
154 (1365)
2094-BM05-M
MPL-B680F
3000
47.9
60.0 (531)
96.0
108 (960)
7.5
2094-BM05-M
MPL-B680H
3500
48.9
58.0 (513)
97.8
107 (947)
7.5
2094-BM05-M
