Avvio/accensione – Rockwell Automation 2727-G7P20D1Q7 MobileView Guard G750 Quick Start User Manual
Page 158
158 MobileView Guard G750
Pubblicazione 2727-QS002E-MU-P
Avvio/Accensione
1. Collegare il cavo di collegamento di MobileView al cavo della scatola di
giunzione come mostrato a pagina 148. Stringere bene la ghiera filettata.
2. Verificare la schermata di avvio sul terminale MobileView.
Se non appare la schermata di avvio, controllare l'alimentazione a 24 V cc e
i collegamenti dei cavi sulla scatola di giunzione e sul terminale MobileView.
SUGGERIMENTO
Un'icona del software RSView ME appare solo sulle schermate
di avvio di MobileView 2727-G7P20D1Q6 e 2727-G7P20D3Q7.
