188 Rockwell Automation Publication 7000A-UM200C-EN-P - June 2014
Appendix F Line & Load Cable Sizes
‘B’ Frame
(Air-
Cooled)
PowerFlex
7000 2400V/60Hz/RPDTD 46...430 70.40, 70.41, 70.44, 70.45 9.79x10.97 (249x279) 1 (2) 500MCM 5kV or 8kV/
phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 2400V/60Hz/RPDTD 46...375 70.40C, 70.41C, 70.44C
w/close-coupled starter 5.61x7.19 (142x183) (1) 500MCM 5kV or 8kV/
phase (1) 253mm² 5kV or
8kV/phase 34.4 (874)
PowerFlex
7000 3300V/50Hz/RPDTD 46...430 70.43, 70.44, 70.45, 70.47 9.79x10.97 (249x279) 1 (2) 500MCM 5kV or 8kV/
phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 3300V/50Hz/RPDTD E495-E625,
G285,
G325, N720 70.32 11.81x16.22 (300x412) 1 (2) 500MCM 5kV
or 8kV/phase (2) 253mm² 5kV
or 8kV/phase 16.5 (421)
PowerFlex
7000 3300V/50Hz/RPDTD 46...375 70.43C, 70.44C,
70.45C, 70.47C
w/close-coupled starter 5.61x7.19 (142x183) (1) 500MCM 5kV or 8kV/
phase (1) 253mm² 5kV or
8kV/phase 34.4 (874)
PowerFlex
7000 4160V/50Hz/RPDTD 46...375 70.43, 70.44, 70.45, 70.47 9.79x10.97 (249x279) 1 (2) 500MCM 5kV or 8kV/
phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 4160V/50Hz/RPDTD 46...375 70.43C, 70.44C,
70.45C, 70.47C
w/close-coupled starter 5.61x7.19 (142x183) (1) 500MCM 5kV or 8kV/
phase (1) 253mm² 5kV or
8kV/phase 34.4 (874)
PowerFlex
7000 4160V/60Hz/RPDTD 46...430 70.43, 70.44, 70.45, 70.47 9.79x10.97 (249x279) 1 (2) 500MCM 5kV or 8kV/
phase (2) 253mm² 8kV or
15kV/phase 28.5 (725)
PowerFlex
7000 4160V/60Hz/RPDTD E495-E625,
G285, G325
N720 70.32 11.81x16.22 (300x412) 1 (2) 500MCM 5kV
or 8kV/phase (2) 253mm² 5kV
or 8kV/phase 16.5 (421)
PowerFlex
7000 4160V/60Hz/RPDTD 46...375 70.43C, 70.44C,
70.45C, 70.47C
w/close-coupled starter 5.61x7.19 (142x183) (1) 500MCM 5kV or 8kV/
phase (1) 253mm² 8kV or
15kV/phase 34.4 (874)
PowerFlex
7000 6600V/50Hz/RPDTD 46...285 70.46, 70.47, 70.48, 70.49 9.79x10.97 (249x279)
1
(2) 500MCM 8kV or
15kV/phase (2) 253mm² 8kV or
15kV/phase 28.5 (725)
PowerFlex
7000 6600V/50Hz/RPDTD E325-E575
G215, G250
N625 70.34, 70.35 12.79x19.68 (325x500) 1 (2) 500MCM 8kV
or 15kV/phase (2) 253mm² 8kV
or 15kV/phase 16.5 (421)
PowerFlex
7000 6600V/50Hz/RPDTD 40...285 70.46C, 70.47C, 70.49C
w/close-coupled starter 5.61x7.19 (142x183) (1) 500MCM 8kV or
15kV/phase (1) 253mm² 8kV or
15kV/phase 34.4 (874)
PowerFlex
7000 6600V/60Hz/RPDTD 40...285 70.46, 70.47, 70.48, 70.49 9.79x10.97 (249x279) 1 (2) 500MCM 8kV or
15kV/phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 6600V/60Hz/RPDTD 40...285 70.46C, 70.47C, 70.49C
w/close-coupled starter 5.61x7.19 (142x183) (1) 500MCM 8kV or
15kV/phase (1) 253mm² 5kV or
8kV/phase 34.4 (874)
PowerFlex
7000 2400V/60Hz/RPTX 46...430 70.1, 70.2, 70.25, 70.26 9.79x10.97 (249x279)
1
(2) 500MCM 5kV or 8kV/
phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 3300V/50Hz/RPTX 46...430 70.10, 70.27, 70.28, 70.30 9.79x10.97 (249x279) 1 (2) 500MCM 8kV or
15kV/phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 3300V/50Hz/RPTX E495-E625
G285, G325
N720 70.32 11.81x16.22 (300x412) 1 (2) 500MCM 5kV
or 8kV/phase (2) 253mm² 5kV
or 8kV/phase 16.5 (421)
PowerFlex
7000 4160V/50Hz/RPTX 46...430 70.10, 70.27, 70.29, 70.30 9.79x10.97 (249x279) 1 (2) 500MCM 8kV or
15kV/phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 4160V/60Hz/RPTX 46...430 70.2, 70.26, 70.27, 70.28,
70.29, 70.31 9.79x10.97 (249x279) 1 (2) 500MCM 8kV or
15kV/phase (2) 253mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 4160V/60Hz/RPTX E495-E625
G285, G325
N720 70.32 11.81x16.22 (300x412)
1
(2) 500MCM 5kV
or 8kV/phase (2) 253mm² 5kV
or 8kV/phase 16.5 (421)
PowerFlex
7000 6600V/50Hz/RPTX 40...285 70.11, 70.28,
70.30, 70.31 9.79x10.97 (249x279) 1 (2) 500MCM
15kV/phase (2) 127mm² 5kV or
8kV/phase 28.5 (725)
PowerFlex
7000 6600V/50Hz/RPTX E325-E575
G215, G250
N625 70.36, 70.37 12.79x19.68 (325x500)
1
(2) 500MCM 8kV
or 15kV/phase (2) 253mm² 8kV
or 15kV/phase 16.5 (421)
PRODUCT INPUT (LINE SIDE)
Bulletin Description
(V/Freq./Rect.)
Drive
rating (A)
Drive Structure Code Drive Enclosure Opening
Inches (mm) 1
Max. Size & No. Incoming
Cables:
NEMA
2-4-5-6-8-9
Max. Size & No.
Incoming Cables:
IEC
2-4-5-6-8-9
Vertical Space
Avail. for
Stress Cones
Inches (mm)
