Chapter 3
Component Definition and Maintenance
The ACB receives all of the Analog Signals from the drive’s internal components.
This includes the current and voltage feedback signals. The boards also have
isolated Digital I/O for fan status, e-stops, and contactor control and status
feedback. All of the test points for the currents, system voltages, control voltages,
and flux are on these boards.
Table 5 - Connectors on Analog Control Board
ACB Connectors
Description
ACB-J1
Control I/O & Control Power Monitor
ACB-J2
Line current inputs, CT2U, CT2W
ACB-J3
Line current inputs, CT3U,CT3W
ACB-J4
Line current inputs, CT4U,CT4W
ACB-J5
Motor current inputs, HECSU, HECSW
ACB-J6
DC Link current inputs, HECSDC1, HECSDC2
ACB-J7
Ground fault & CMC Neutral current inputs, GFCT, INN
ACB-J8
Isolated & Non-isolated analog inputs, AIN1,AIN2,AIN3
and Non-isolated outputs, AOUT1, AOUT2, AOUT3, AOUT4
ACB-J9
Air pressure inputs, AP0, AP1
ACB-J10
Meter outputs, AOUT5, AOUT6, AOUT7, AOUT8 and Speed Pot input, AIN0
ACB-J11
Communication connections, printer outputs
ACB-J12
Communication connections, Terminal
ACB-J13
DC power supplies, XIO(+24V),+/-15V,+/-24V,+5V
ACB-J14
DC power supply monitoring, 5V1, 5V2, DC-BUS
ACB-J15
DC-ABUS +56V output monitoring (UPS option)
ACB-J16
DPI interface
ACB-J17
Communication connections, scan port
ACB-J18
DC fail signal monitoring
ACB-J19
DC fail signal monitoring
ACB-J20
DC fail signal monitoring
ACB-J21
DC fail signal monitoring
ACB-J22
Communication connection, XIO link CAN interface
ACB-J23
Communication connection, parallel drive
ACB-J24
UPS fail signal monitoring
ACB-J25
Line voltage synchronous transfer feedback voltage inputs VSA,VSB,VSC
ACB-J26
Motor & line DC link and Neutral Point Voltage inputs
ACB-J27
AC Motor & Line voltage feedback inputs
ACB-J28
Encoder interface
ACB-J30
DPM connection, A/D SUB system
ACB-J31
DPM connection, DACs serial data
ACB-J32
DPM power supply, +5V
ACB-J33
DPM connection, Faults & other I/O
ACB-J34
DPM connection, Encoder
