Rockwell Automation Publication 7000A-UM200C-EN-P - June 2014 187
Appendix
F
Line & Load Cable Sizes
Max. Line Cable Sizes
PRODUCT INPUT (LINE SIDE)
Bulletin Description
(V/Freq./Rect.)
Drive
rating (A)
Drive Structure Code Drive Enclosure Opening
Inches (mm) 1
Max. Size & No. Incoming
Cables:
NEMA
2-4-5-6-8-9
Max. Size & No.
Incoming Cables:
IEC
2-4-5-6-8-9
Vertical Space
Avail. for
Stress Cones
Inches (mm)
‘A’ Frame
(Air-
Cooled)
PowerFlex
7000A 2400V/60Hz/RPDTD 46...140 71.9 w/ starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 18.8 (478)
PowerFlex
7000A 2400V/60Hz/RPDTD 46...140 71.13, 71.18 w/o starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 17.1 (435)
PowerFlex
7000A 3300V/50Hz/RPDTD 46...140 71.9 w/ starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 18.8 (478)
PowerFlex
7000A 3300V/50Hz/RPDTD 46...140 71.13, 71.18 w/o starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 17.1 (435)
PowerFlex
7000A 4160V/50Hz/RPDTD 46...140 71.9 w/ starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 18.8 (478)
PowerFlex
7000A 4160V/50Hz/RPDTD 46...140 71.13, 71.18 w/o starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 17.1 (435)
PowerFlex
7000A 4160V/60Hz/RPDTD 46...140 71.9 w/ starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 18-3/8 (467)
PowerFlex
7000A 4160V/60Hz/RPDTD 46...140 71.13, 71.18 w/o starter 4.00x4.00 (102x102) (1) #4/0 5 kV or
8 kV/phase (1) 107mm² 5 kV or
8 kV/phase 17.1 (435)
PowerFlex
7000A 6600V/50Hz/RPDTD 40...93 71.10 w/ starter 4.00x4.00 (102x102) (1) #4/0 8 kV or
15 kV/phase (1) 107mm² 5 kV or
8 kV/phase 18.8 (478)
PowerFlex
7000A 6600V/50Hz RPDTD 40...93 71.14, 71.19 w/o starter 4.00x4.00 (102x102) (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 8 kV or
15 kV/phase 17.1 (435)
PowerFlex
7000A 2400V/60Hz/RPTX 46...160 71.7 4.00x8.00 (102x204) 1
(1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 5 kV or
8 kV/phase 33.8 (860)
PowerFlex
7000A 3300V/50Hz/RPTX 46...160 71.7 4.00x8.00 (102x204) 1 (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 8 kV or
15 kV/phase 33.8 (860)
PowerFlex
7000A 4160/50Hz/RPTX 46...160 71.7 4.00x8.00 (102x204) 1 (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 8 kV or
15 kV/phase 33.8 (860)
PowerFlex
7000A 4160/60Hz/RPTX 46...160 71.7 4.00x8.00 (102x204) 1 (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 8 kV or
15 kV/phase 33.8 (860)
PowerFlex
7000A 6600/50Hz/RPTX 40...105 71.8 4.00x8.00 (102x204)
1
(1) 350MCM
15 kV/phase (1) 177mm²
15 kV/phase 33.8 (860)
PowerFlex
7000A 2400V/60Hz/RPTXI 46...160 71.3 4.00x4.00 (102x102) (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 5 kV or
8 kV/phase 20.0 (508) 3
PowerFlex
7000A 3300V/50Hz/RPTXI 46...160 71.3 4.00x4.00 (102x102) (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 5 kV or
8 kV/phase 20.0 (508) 3
PowerFlex
7000A 4160V/50Hz/RPTXI 46...140 71.3 4.00x4.00 (102x102) (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 5 kV or
8 kV/phase 20.0 (508)
3
PowerFlex
7000A 4160V/60Hz/RPTXI 46...160 71.3 4.00x4.00 (102x102) (1) 350MCM
8 kV or 15 kV/phase (1) 177mm² 5 kV or
8 kV/phase 20.0 (508) 3
PowerFlex
7000A 6600V/50Hz/RPTXI 40...105 71.6, 71.15 4.00x4.00 (102x102) (1) #4/0 8 kV or
15 kV/phase (1) 177mm² 8 kV or
15 kV/phase 20.0 (508) 3
