Quickstart project for 2080-dnet20 plug-in, Quickstart – Rockwell Automation 2080 Micro800 Digital and Analog Plug-in Modules User Manual
Page 87
Rockwell Automation Publication 2080-UM004B-EN-E - December 2013
79
Quickstart Appendix B
• Right-click the plug-in slot in the Controller Properties tree and choose
the plug-in you would like to add.
.
The device configuration window should show the added plug-in
modules:
Quickstart Project for
2080-DNET20 Plug-in
Using your 2080-DNET20 plug-in module and user defined function blocks in
Connected Components Workbench, the following quickstart project shows you
how to turn on all the outputs of a CompactBlock LDX module connected in
Node 3.
IMPORTANT
Quickstart Prerequisite
For the following quickstart projects, you first need first need to
download the DNET UDFBs and sample project from the
Sample Code Library:
