Rockwell Automation Publication 2080-UM004B-EN-E - December 2013
95
Appendix
C
Error Codes
Troubleshooting
For troubleshooting your Micro800 controller system, see the User Manual for
your controller:
• Micro830 and Micro850 Programmable Controllers User Manual,
publication
.
• Micro820 Programmable Controllers User Manual, publication
Error Codes for Micro800
Plug-ins
This section lists possible error codes for your plug-in modules, as well as
recommended actions for recovery.
If an error persists after performing the recommended action, contact your local
Rockwell Automation technical support representative. For contact information,
go to
List of Error Codes for Micro800 Plug-ins
Error Code
Description
Recommended Action
For the following four error codes, z refers to the slot number of the plug-in module. If z = 0, then the slot number cannot be identified
0xF0Az
The plug-in I/O module has encountered an error
during operation.
Perform one of the following:
• Check the condition and operation of the plug-in I/O module.
• Cycle power to the Micro800 controller.
0xF0Bz
The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform one of the following:
• Correct the plug-in I/O module configuration in the user program to match
that of the actual hardware configuration.
• Check the condition and operation of the plug-in I/O module.
• Cycle power to the Micro800 controller.
• Replace the plug-in I/O module.
0xF0Dz
A hardware error has occurred while power was
being applied to the plug-in module or the plug-in
module was removed.
Perform the following:
• Correct the plug-in I/O module configuration in the user program.
• Build and download the program using Connected Components Workbench.
• Put the Micro800 controller into Run mode.
0xF0Ez
The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform the following:
• Correct the plug-in I/O module configuration in the user program.
• Build and download the program using Connected Components Workbench.
• Put the Micro800 controller into Run mode.
