DeviceNet Plug-in – 2080-DNET20 Appendix 5
RA_DNET_LDX_TC_RTD
This UDFB is used to read input data from the Thermocouple/RTD module.
AO_Ch0
INPUT
WORD
Analog Output Channel 0 value.
This value is valid only if Module1 = '0X2'
AO_Ch0
INPUT
WORD
Analog Output Channel 1 value.
This value is valid only if Module1 = '0X2'
DO_Module2
INPUT
UINT
Output data for Expansion Module 1.
DO_Module3
INPUT
UINT
Output Data for Expansion Module 2.
FBENO
OUTPUT
BOOL
Function block enable output.
TRUE upon exit.
AI_CH0
OUTPUT
WORD
Analog Input Channel 0 value.
This value is valid only if Module1 = '4X0'
AI_CH1
OUTPUT
WORD
Analog Input Channel 1 value.
This value is valid only if Module1 = '4X0'
AI_CH2
OUTPUT
WORD
Analog Input Channel 2 value.
This value is valid only if Module1 = '4X0'
AI_CH3
OUTPUT
WORD
Analog Input Channel 3 Value.
This value is valid only if Module1 = '4X0'
StatusCH0_3
OUTPUT
WORD
Analog input channel 0…3 status
DI_Module2
OUTPUT
UINT
Digital Expansion Module 1 Input Data.
Applicable only if catalog is with digital inputs.
DI_Module3
OUTPUT
UINT
Digital Expansion Module 2 Input Data.
Applicable only if catalog is with digital inputs.
(1) Use only valid strings combinations as mentioned above. If Module1, Module2, Module3 physical I/O does not
match the physical I/O present in base and expansion, then incorrect sequence will be written.
RA_DNET_LDX_TC_RTD: Input and Output Parameters
Variable Name
Type
Data Type
Description
FBEN
INPUT
BOOL
Function block enable input.
TRUE to enable function.
SlotID
INPUT
UINT
Plug-in slot number (1…5)
NodeID
INPUT
USINT
Node address of the digital Compact I/O slave node.
FBENO
OUTPUT
BOOL
Function block enable output.
CH0
OUTPUT
WORD
RTD/Thermocouple input channel 0 value.
CH1
OUTPUT
WORD
RTD/Thermocouple input channel 1 value.
CH2
OUTPUT
WORD
RTD/Thermocouple input channel 2 value.
CH3
OUTPUT
WORD
RTD/Thermocouple input channel 3 value.
StatusCH0_3
OUTPUT
WORD
RTD/Thermocouple Input channel 0…3 status.
RA_DNET_LDX_ANALOG: Input and Output Parameters
Variable Name
Type
Data Type
Description
FBEN
SlotID
NodeID
FBENO
CH0
CH1
CH2
CH3
StatusCH0_3
RA_DNET_LDX_TC_RTD
