Chapter 5
Configuring DFA Instructions
5-4
If you are configuring a new program, you need to download the
DFA CAR file. If not, go to “Entering or Modifying a DFA
Instruction” on page 5-5.
Download the DFA CAR file
Important: To download the DFA CAR file you must be in online
Program mode.
To download the DFA CAR file into your program, do the following steps:
1. Press [F2] - Save Restore.
The system displays the Save Restore function keys.
2. Press [F4] - Restore Program.
The system displays a window containing a file directory of a
specific type (see the figure below).
File Directory Window (PLC-5)
+= PROGRAM DIRECTORY FOR PROCESSOR: += D:\IPDS\ARCH\PLC5\*.CAR ==============+=+
| File Name | Name Size Date Time | |
|–––––––––––––––––––––––––––––––––––|––––––––––––––––––––––––––––––––––––––––|–|
| 0 | DFA5 936 9–06–91 10:11a | |
| 1 | SDS5 5672 9–06–91 10:10a | |
| 2 | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
| | | |
+===================================+========================================+=+
Press a function key or enter file name or move cursor to select file.
>
Program PLC–5/25 Series A Revision H 5/25 Addr 1 SDSC5
Begin Define Select Save Fl Conv
Restore Dirctry Type Config Utility
F1 F7 F8 F9 F10
3. Press [F8] - Select Type until the CAR directory appears in the
file directory window.
