Configuring SDS Instructions
Chapter 4
4-21
Address Comment Editor Screen (PLC-5)
Smart Directed Sequencer I/O Input Defines Output Defines
Definition for Control Block 0: I:001/16 0: O:000/04
N10:0 1: I:001/15 1: O:000/01
2: I:001/14 2: O:000/02
3: B3/2 3:
+=Ins Cmt==+ +=Adr Cmt==+ 4: B3/3 4:
|DRILL | |FULL | 5: 5:
|MACHINE | |DEPTH LS | 6: 6:
|HEAD 1 | | | 7: 7:
| | | |
| | | |
+==========+ +==========+
Operator Interface Station Addr : 77
Timebase for Step Timer : 0.01
Enter address comment for : I:001/14
Program Edit mode:Insert Col:1 Line:1 PLC–5/25 Addr 1
Delete Undel Delete Undel Delete Undel Accept/ Next Prev
Comment Comment Line Line Word Word Exit Address Address
F1 F2 F3 F4 F5 F6 F8 F9 F10
2. Edit the instruction or address comment. The function keys for both
Editor screens are the same, except that the Address Comment Editor
screen has function keys for moving the cursor to the next or previous
address:
If you want to: Press this key:
Delete the current comment. [F1] - Delete Comment
Re-insert the last deleted comment where the cursor is. [F2] - Undel Comment
Delete the line the cursor is on from the current
comment. [F3] - Delete Line
Re-insert the last deleted line from a comment. [F4] - Undel Line
Delete the word the cursor is on from the current
comment. [F5] - Delete Word
Re-insert the last deleted word from a comment. [F6] - Undel Word
Save the current comment and return to the I/O
Definition screen. [F8] - Accept/Exit
For Address Comments Only:
Save the current comment and/or move the cursor to
the next address.
[F9] - Next Address
Save the current comment and/or move the cursor to
the previous address. [F10] - Prev Address
3. When you are finished, press [F8] - Accept/Exit.
