Configuring SDS Instructions
Chapter 4
4-18
7. Press [F10] - Accept Rung .
Important: You must accept the rung to save the information you entered
into the SDS instruction.
The SDS instruction provides a documentation function that lets you describe
the instruction and its associated addresses. The documentation function also
lets you assign symbols to addresses.
To document your SDS, Press [F5] - Documnt from the I/O Definition screen.
The system displays the SDS Instruction Documentation screen.
SDS Instruction Documentation Screen (PLC-5)
Smart Directed Sequencer I/O Input Defines Output Defines
Definition for Control Block 0: I:001/16 0: O:000/04
N10:0 1: I:001/15 1: O:000/01
2: I:001/14 2: O:000/02
3: B3/2 3:
+=Ins Cmt==+ +=Adr Cmt==+ 4: B3/3 4:
|DRILL | |RETURNED L| 5: 5:
|MACHINE | |S | 6: 6:
|HEAD 1 | | | 7: 7:
| | | |
| | | |
+==========+ +==========+
Operator Interface Station Addr : 77
Timebase for Step Timer : 0.01
Press a function key.
Program Forces:None Data:Decimal Addr:Decimal PLC–5/25 Addr 1
Instr Address Modify Remove Display Save &
Comment Comment Symbol Symbol Symbol Contnue
F2 F3 F6 F7 F9 F10
Documenting the SDS
Instruction
