Rockwell Automation 1785-ENET USER MANUAL PLC-5 ETHERNET INTERFACE - Manual (Page 47)

1785-6.5.19 November 1998
SNMP Management Information Base (MIB) II Data Groups C-3
IP (continued) ipRouteProto mechanism used to determine route
ipRouteAge age of route in seconds
ipRouteMask subnet mask for route
ipNetToMediaflIndex interface number
ipNetToMediaPhysAddress media address of mapping
ipNetToMediaNetAddress IP address of mapping
ipNetToMediaType how mapping was detemined
ipReasmReqds fragments received needing reassembly
ipReasmOKs datagrams successfully reassembled
ipReasmFails reassembly failure
ipFragOKs datagrams successfully fragmented
ipFragCreates fragments created
ipAdEntAddr the IP address of this entry
ipAdEntflIndex interface number
ipAdEntNetMask subnet mask for IP address
ipAdEntBcastAddr LSB of IP broadcast address
ipAdEntReasMaxSize the largest IP datagram able to be reassembled
ICMP 26 counters two counters for each ICMP message type
TCP tcpRtoAlgorithm identifies retransmission algorithm
tcpRtoMin minimum retransmission timeout in milliseconds
tcpRtoMax maximum retransmission timeout in milliseconds
tcpmaxConn maximum of simultaneous TCP connections allowed
tcpActiveOpens number of active opens
tcpPassiveOpens number of passive opens
tcpAttemptFails number of failed connection attempts
tcpEstabResets number of connections reset
tcpCurrEstab number of current connections
Group: MIB: Description:
