What you have done, What’s next – Rockwell Automation 1785-ENET USER MANUAL PLC-5 ETHERNET INTERFACE User Manual
Page 15
1785-6.5.19 November 1998
Quick Start
1-7
What You Have Done
You have now successfully installed and configured the PLC-5
Ethernet interface module for operation with the attached processor
on an Ethernet link. If your module is operating successfully, it is not
necessary to continue reading this manual.
For more information about operation PLC-5 processors within your
control system, see the Enhanced and Ethernet PLC-5 Programmable
Controller User Manual, publication 1785-6.5.12.
What’s Next
If necessary, see the remainder of this manual for more detailed
information about installing and configuring the interface module.
For information about
See
installing the interface module
chapter 2
configuring the interface module for Ethernet communication
chapter 3
communicating over Ethernet via the interface module
chapter 4
interface module specifications
appendix A
