Rockwell Automation Publication 1791ES-UM001D-EN-P - May 2013
47
Chapter
5
Configure the I/O Modules by Using the Logix
Designer Application
Use Help
At the bottom of a dialog box, choose Help for information about how to
complete entries in the dialog box. At the bottom of a warning dialog box, choose
Help to get information about that specific error.
Add Modules to the I/O
Configuration Tree
To add a module to the I/O configuration tree, follow these guidelines.
Topic
Page
Add Modules to the I/O Configuration Tree
Use the Module Properties and General Dialogs
Work with the Input Configuration Dialog
Work with Test Output Configuration Dialog
Work with the Output Configuration Dialog
