Understand the Operation of Safety Functions
Read this chapter for information related to the safety functions of the modules.
Also included is a brief overview on international standards and directives that
you must be familiar with.
The following status is the safety state of the Guard I/O modules:
• Safety outputs: off
• Safety input data to network: off
Figure 3 - Safety Status
The module is designed for use in applications where the safety state is the off
state.
