6–4 Module Calibration
Publication 1771ĆUM127B-EN-P - December 2002
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 Word/Dec. Bit
00 01 02 03 04 05 06 07 10 11 12 13 14 15 16 17 Word/Octal Bit
9 3rd High Output Cal Value
10 4th Low Output Cal Value
11 4th High Output Cal Value
12 5th Low Output Cal Value
13 5th High Output Cal Value
14 6th Low Output Cal Value
15 6th High Output Cal Value
16 7th Low Output Cal Value
17 7th High Output Cal Value
18 8th Low Output Cal Value
19 8th High Output Cal Value
2. Apply the appropriate low reference signal (Table 6.D) to all
input channels being calibrated (for channel 1, I1 on RTP).
Table 6.D
Calibration Reference Signal Values
Type Low Reference Value High Reference Value
5 Volt input 0.0000V 5.0000V
10V input 0.0000V 10.0000V
4-20mA sourcinginput 1.000mA 21.000mA
-5 to 55mV/TC input 0.000mV 55.000mV
100mV/TC input 0.000mV 100.000mV
650 Ohm RTD input 1.000 Ohms 649.0 Ohms
10V output 0.000V 10.000V
25mA output 0.500mA 22.000mA
50mA output 1.000mA 50.000mA
