Block Transfer Write and Block Transfer Read Configurations for 1 Output/7 Input 1771-N Series Modules
F–3
Publication 1771ĆUM127B-EN-P - December 2002
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
Word/Dec. Bit
00
01
02
03
04
05
06
07
10
11
12
13
14
15
16
17
Word/Octal Bit
49
Alarm
enable
Rate Alarm: Scaled Units per second
50
Filter Time Constant: 0.1 second units
Alarm Deadband
51
Thermocouple Type
0
RTD Type
10 Ohm Offset: 0.01 Ohm units
Channel 8 Programming
52
Low Scale Value
53
High Scale Value
54
Low Alarm Value
55
High Alarm Value
56
Alarm
enable
Rate Alarm: Scaled Units per second
57
Filter Time Constant: 0.1 second units
Alarm Deadband
58
Thermocouple Type
0
RTD Type
10 Ohm Offset: 0.01 Ohm units
Block Transfer Write Bit/Word Descriptions for 1 Output/7 Input
Modules
Word
Decimal Bit
(Octal Bit)
Definition
00-03
Constant = 0
Bits 04-07
Number of outputs = 0001
Word 0
Bits 09-13
(10-15)
Constant = 00 1000
Bits 14-15
(16-17)
Block transfer write type = 10
Word 1
Bits 00-15
(00-17)
First Output channel data
Word 2
Bit 00
Verify. If this bit is set to 1, the module will compare its current
programming with the programming downloaded in the BTW. If
they are the same, it will verify good; if they are different, the
module will verify bad. In no case will any programming data in
the BTW be applied to the module.
Bit 01
Temperature scale. 0 = Celsius, 1 = Fahrenheit
Bit 02
BCD select.
1 = all values in BCD format.
0 = all values in 2's complement binary
Bits 03-14
(03-16)
Not used. Always 0
Word 2 continued
Bit 15 (17)
CJ alarm enable. A value of 1 enables over and underrange
indication for the cold junction channel. If the module does not
have a cold junction channel, this bit is 0.
