Dual Trunk E1 Router
Dual Trunk E1 Router User’s Guide
TECHNICAL: 0118 96 56 000
33
Access Configuration
4
O
VERVIEW
OF
A
CCESS
C
ONFIGURATION
This chapter contains information about configuring the LAN and WAN interfaces, the interface IP
addresses, NMS IP addresses, Radius authentication, DHCP, and miscellanous management settings
Table 4-1
Access configuration procedures
Procedure
Description
Menu
Reference
Configuring LAN
interface
To set or modify the Ethernet data port IP address and subnet mask,
and the ethernet speed (10MB/Half or 10MB/Full).
Menu-0A
Menu-0C
Setting Unit ID, Date,
Time, and E1 Network
To configure the network E1 timing, framing, and coding.
Menu-4A
Menu-4B
Allocating Timeslot for
data and voice
To allocate and map fractional dual E1 bandwidth to the Ethernet data
port
Menu-6Z
Configuring WAN
protocol
To configure the WAN protocol to:
• Single link PPP interface
• Dual independent PPP link interfaces
• Multilink PPP (MLPPP) interface
• Single link Frame Relay interface
• Dual links Frame Relay interfaces
• Multilink Frame Relay (MFR) interface
Menu-0A
Configuring Frame Relay
DLCIs
To configure statically the DLCI numbers with associated interface.
Menu-0E
Configuring Link
Management Information
To enable or disable LMI, and configure LMI settings, unit location
UNIT-U or UNI-N
Menu-0F
Mapping DLCIs to IP
addresses
To configure the mapping of DLCI to the next hop IP addresses
statically and manually.
Menu-$IA
Configuring SLIP
To configure SLIP (Serial Line Interface Protocol) to allow telnet
access through the COMM port.
Menu-0A
Configuring Access
Rights
To set the TUI normal and superuser access levels.
Menu-8C
Configuring Radius
Authentication
To configure Radius authentication, user login and password,
preventing unauthorized access and changes to the access router TUI.
Menu-8G
Enabling/Disabling Traffic
Monitoring (Optional)
To enable or disable the router from collecting and reporting RMON-1,
and RMON-2 statistics.
To enable or disable Frame Relay SLA and configure Frame Relay
SLA statistics.
By default Traffic monitoring is disabled.
Menu-0A
Menu-0H
