1.2 Abbreviations and notes
1.2.1 Abbreviations
Abbreviations Meaning
Battery Power supply unit
BA Opening coil
BC Closing coil
CB Circuit Breaker
CS Current Sensor (current transformer)
Dialog Communication module
HW Hardware
In Rated current of the Rating Plug installed in the circuit breaker
LSIG Protection relay for CB 140G-N/140G-NS/140G-R
LSIG-MM Protection relay for CB 140G-N/140G-NS
MT Thermal memory
Relay also called "protection unit" or "protection release"
RMS Root mean square value
TC Trip Coil (opening solenoid)
SW Software
i-Test "Info/test" button on the front of the relay
Trip CB opening, generated by the release
Vaux Auxiliary power supply
1.2.2 Notes
A. Use the "Belden 3105A"- type two-wire cable for instance (not supplied by AB).
B. Use the "Belden 3106A"- type three-wire cable for instance (not supplied by AB).
C. The unit has a "backup-protection" function; if the first command to the opening solenoid does not immediately open the circuit-breaker (TC
partially faulty), TRIP commands are repeatedly sent until the circuit-breaker opens (providing a Vaux is fitted) or the current disappears (if
self-powered). The "backup" condition can be signalled by configuring the unit relays; using the "YO back" selection, it is possible to command
the "opening coil (YO)" accessory as another opening device when TC does not work.
1.2.3 Compatibility between CB and relay
This table summarizes all possible fitting of the relays and 140G circuit breakers.
CB\Relay LSIG LSIG-MM
140G/N/140G-NS x x
140G-R x x
