3.3.4 Default settings
The LSIG-MM are supplied by AB with the following predefined parameters (Set A and Set B):
# Protection On/Off Thresholds Time Curve T.M. Trip
1 L — 1 In 144 s I 2 t Off —
2 S Off 6 In 50 ms K — —
3 I On 4 In — — — —
4 G Off 0.2 In 0.4 s K — On
5 U Off 50 % 5 s Off
6 OT — Off
7 Language — Engl
8 Mains frequency — (1)
9 Sel. Neutral — (2)
10 S startup Off 6 In 100 ms
11 G startup Off 1 In 100 ms
12 Password — 0001
13 Measurement interval — 60 min
14 Iw Off 3 In
15 MM On 2.5 In — — —
Note:
(1) = 50Hz for automatic Circuit-Breakers IEC
60Hz for automatic Circuit-Breakers UL
(2) = off for 3-pole version
50% for 4-pole version
