You will be prompted to input a Password
complete password entry procedure (par. 3.2.5)
press the ↵ key (enter)
Select the value you want from the list
And confirm by pressing the ↵ key (enter).
Press ESC twice
Before accessing the Main Menu, the following box will appear:
Accept the new configuration
Reject the new configuration (the previous configuration is retained)
Change previously input values.
To select the required option use the ↓ (arrow down), ↑ (arrow up) keys, and press ↵ (enter) to confirm.
3.3.3.1 Modification of basic configuration
No parameters can be set when the LSIG-MM unit is in alarm conditions.
The unit must be configured in EDIT mode.
Following the instructions given in par. 3.4.3, view the following on the display:
Change system date
Change System Time
Select system language
To change system password, select the relevant menu item and press ↵ (enter); then you will be prompted to enter the OLD password, and
afterwards you can input the new one twice.
Press ESC twice to return to the Main Menu.
Before accessing the Main Menu, the following box will appear:
Accept the new configuration
Reject the new configuration (the previous configuration is retained)
Change previously input values.
Note: to set system language check that:
- The relay is set to local (if communication module is installed)
- CB is open
- Auxiliary power supply is provided (Vaux 24VDC or battery unit).
If one of the conditions mentioned above is not complied with, the relay does not allow changing language.
1/3
Confirm
Abort
Modify
Confirm
Programming
1/3
Confirm
Abort
Modify
Confirm
Programming
1/4
January 12, 2013
Time
Language
Date
System
4/4
****
Language
New Password
Time
System Password
Enter password
0***
1/4
t=0.14b/(i -1) 0.02
T=13.5b/(i-1)
t=k/i 2
Function
Password
Enter password
0***
