Rockwell Automation 140G-NTK-E12 LSIG and LSIG-MM Release User Manual
Page 28
DIR 1000587R0002 (L3821)
(28)
Failure to comply with the setting limits for “I
n
” and “I
n
N” can cause damage to circuit breaker with consequent risks even
for operator.
In any case, the relay records any setting error between
I
1
and Neutral setting, and it signals this by means of a warning (see par. 3.5.2).
For
4-pole CBs only.
3.4.4.3
Mains frequency settings
In the Mains frequency menu, frequency values: 50, 60 Hz can be selected.
2/9
50 Hz
Main Frequency
Modules
Circuit Breaker
Settings
Password
Enter password
0***
1/2
4 P
60 Hz
50 Hz
Main Frequency
Enter ↵
Enter ↵
3.4.4.4 Modules
3.4.4.4.1 Communication module
Local or remote modes can be set after entering a password. The serial address can be displayed after entering a password. Baud Rate can be
set to 9600 and 19200 bit/s. The physical protocol provides for options: (8,E,1), (8,O,1), (8,N,2), (8,N,1). For further information on the communi-
cation module, see paragraph 4.2 in this manual.
3.4.5 Test Menu
Access to the Test menu is password-protected.
The menu shows the state of the CB; the dialog module (COM module), the state of the springs and the position of the CB; and in this submenu
you can have the CB opened or closed.
Using the “Trip Test” function, Trip disabling/enabling can be viewed. When enabled, the circuit breaker is opened. This function is only available
with a nil busbar current (use Vaux or battery unit).
On the page, only with Vaux, you can also see the state of “STATUS” circuit breaker, thus making sure that input is correctly wired.
The surfing path is summarized in the following table:
3.4.5.1
Test Menu table
Parameter/Function
Values
Notes
CB status
Open/Closed/Indefinite
Indefinite only in the event of a fault
Auto Test
Display test
Trip Test
Enabled/Disabled
Communication State of springs
Unloaded/Loaded
module
Position of CB
Isolated/Withdrawn
Open CB
Close CB
MM Test
Autotest
2/4
Parametri di comunicazione
Module
COM
Moduli
1/5
Locale
Indirizzo Seriale
BaudRate
Local / Remote
Modulo COM
4/5
Device test
Settings
Test
Measures
Menu
Password
Enter password
0***
1/6
CB open
Auto Test
Trip Test (disabled)
CB status
Test
Enter ↵
Enter ↵
