Other types of shielded cable are available, but the selection of these types can
limit the allowable cable length. Particularly, some of the newer cables bundle 4
conductors of THHN wire and wrap them tightly with a foil shield. This
construction can greatly increase the cable charging current required and reduce
the overall drive performance. Unless specified in the individual distance tables as
tested with the drive, these cables are not recommended and their performance
against the lead length limits supplied is not known. See
Table 3 .
Table 3 - Recommended Shielded Wire
Single-Phase Input Power – Frame 7 Only
The PowerFlex 700 drive is typically used with a three-phase input supply. Frame
7 drives have been listed by UL to operate on single-phase input power with the
requirement that the output current is derated by 50% (at maximum ambient
temperature of 25 °C) of the three-phase ratings. Refer to
Table 4 on page 33 .
AC Input Phase Selection
Moving the “Line Type” jumper on the Precharge Board (see below) allows single
or three-phase operation.
Location Rating/Type Description
Standard
(Option 1) 600V, 90 °C (194 °F)
XHHW2/RHW-2 Anixter
B209500-B209507, Belden
29501-29507, or equivalent • Four tinned copper conductors with XLPE insulation.
• Copper braid/aluminum foil combination shield and tinned
copper drain wire.
• PVC jacket.
Standard
(Option 2) Tray rated 600V, 90 °C
(194 °F) RHH/RHW-2 Anixter
OLF-7xxxxx or equivalent • Three tinned copper conductors with XLPE insulation.
• 5 mil single helical copper tape (25% overlap min.) with three
bare copper grounds in contact with shield.
• PVC jacket.
Class I & II;
Division I & II Tray rated 600V, 90 °C
(194 °F) RHH/RHW-2 Anixter 7V-
7xxxx-3G or equivalent • Three bare copper conductors with XLPE insulation and
impervious corrugated continuously welded aluminum armor.
• Black sunlight resistant PVC jacket overall.
• Three copper grounds on #10 AWG and smaller.
ATTENTION: To avoid a shock hazard, ensure that all power to the drive has
been removed before performing the following.
IMPORTANT Frames 8…10 are not designed for single-phase operation.
IMPORTANT When selecting single-phase operation, input power must be applied to the R
(L1) and S (L2) terminals. This ensures that the fan is properly powered.
