PERFORMANCE DATA (cont)
EVAPORATOR-FAN MOTOR PERFORMANCE — HIGH-STATIC MOTORS
LEGEND
Bhp — Brake Horsepower
*Extensive motor and electrical testing on these units ensures that the full horsepower and watts range of the motors
can be utilized with confidence. Using your fan motors up to the ratings shown in this table will not result in nuisance
tripping or premature motor failure. Unit warranty will not be affected.
ACCESSORY/FIOP ECONOMIZERS AND
ELECTRIC HEATERS STATIC PRESSURE DROP (in. wg)
551B036-072
LEGEND
FIOP — Factory-Installed Option
ACCESSORY/FIOP ECONOMIZERS AND
ELECTRIC HEATERS STATIC PRESSURE DROP (in. wg)
551B090-150
LEGEND
FIOP — Factory-Installed Option
EVAPORATOR-FAN MOTOR EFFICIENCY
*Single-phase/3-phase.
NOTE: Convert watts to bhp using the following formula:
FIOP PERFECT HUMIDITY™ DEHUMIDIFICATION
PACKAGE STATIC PRESSURE DROP (in. wg)
LEGEND
FIOP — Factory-Installed Option
UNIT
551B
UNIT
PHASE
MAXIMUM
CONTINUOUS BHP*
MAXIMUM
OPERATING WATTS*
UNIT VOLTAGE
MAXIMUM
AMP DRAW
036
Three
2.40
2120
208/230
6.7
460
3.0
575
3.0
048
Three
2.40
2120
208/230
6.7
460
3.0
575
3.0
060
Three
2.90
2615
208/230
8.6
460
3.9
575
3.9
072
Three
2.90
2615
208/230
8.6
460
3.9
575
3.9
090,102
Three
4.20
3775
208/230
12.2
460
5.5
575
5.5
120
Three
5.25
4400
208/230
17.3
460
8.5
575
8.5
COMPONENT
CFM
900 1200 1400 1600 1800 2000 2200 2400 2600
1 Heater
Module
0.05 0.07
0.09
0.09
0.10
0.11
0.11
0.12
0.13
2 Heater
Modules
0.15 0.16
0.16
0.16
0.17
0.17
0.17
0.18
0.18
EconoMi$er
0.05 0.09
0.13
0.17
0.22
0.27
0.32
0.39
0.45
COMPONENT
CFM
2200 2500 3000 3500 4000 4500 5000 5500 6000
1 Heater
Module
0.02
0.03 0.05
0.065 0.08
0.10
0.12
0.14 0.155
2 Heater
Modules
0.03
0.05 0.07
0.09
0.12
0.14
0.16
0.19 0.21
EconoMi$er
0.07
0.09 0.13
0.18
0.23
0.30
0.36
—
—
MOTOR 551B
EFFICIENCY
036,048
75
060
74/84*
072
84
090,102
80
120
85
150
87
bhp =
watts input x motor efficiency
746
UNIT SIZE
551B
UNIT NOMINAL
TONS
CFM PER TON
300
400
500
036
3
.04
.07
.09
048
4
.07
.12
.15
060
5
.09
.15
.21
072
6
.12
.20
.28
090
7
1
/
2
.08
.13
.18
102
8
1
/
2
.10
.15
.22
120
10
.08
.13
.18
150
12
1
/
2
.11
.18
.26
0
T
F
Q
0
04
-0
12
55
1B0
3
6-
15
