PERFORMANCE DATA (cont)
ELECTRIC HEATING CAPACITIES
*Two heater packages required to provide kW indicated.
†009 for 558F102 units.
**On units with factory-installed outlet, use CRSINGLE014A00.
NOTES:
1. The kW ratings shown above are at 240, 480, and 600 v. Use the Multiplica-
tion Factors table below to determine heater capacity for your particular
voltage.
MULTIPLICATION FACTORS
Example: 32.0 kW (at 240 v) heater on 208 v
= 32.0 (.75 mult factor)
= 24.0 kW capacity at 208 v
2. Heaters are not available for size 036-072 575-v units.
UNIT
558F
VOLTAGE
(60 Hz)
ACCESSORY
kW
ACCESSORY
HEATER
PART NUMBER
CRHEATER---A00
ACCESSORY
SINGLE POINT BOX
PART NO.
CRSINGLE---A00
036
208/230
(single
phase)
4.4
101
—
6.5
102
—
8.7
103
—
10.5
104
—
13.0*
102*
004
208/230
(3 phase)
4.4
101
—
6.5
102
—
8.7
103
—
10.5
104
—
16.0
105
—
460
(3 phase)
6.0
106
—
8.8
107
—
11.5
108
—
14.0
109
—
048
208/230
(single
phase)
4.4
101
—
8.7
103
—
13.0*
102*
004
17.4*
103*
004
21.0*
104*
004
208/230
(3 phase)
6.5
102
—
8.7
103
—
16.0
105
—
21.0*
104*
002
460
(3 phase)
6.0
106
—
11.5
108
—
14.0
109
—
23.0*
108*
—
060
208/230
(single
phase)
6.5
102
—
8.7
103
—
13.0*
102*
004
17.4*
103*
004
21.0*
104*
004
208/230
(3 phase)
6.5
102
—
10.5
104
—
16.0
105
—
21.0*
104*
002
26.5*
105,104
002
460
(3 phase)
6.0
106
—
11.5
108
—
14.0
109
—
23.0*
108*
—
25.5*
109,108
—
072
208/230
(3 phase)
6.5
102
—
10.5
104
—
16.0
105
—
21.0*
104*
002
26.5*
105,104
002
460
(3 phase)
6.0
106
—
11.5
108
—
14.0
109
—
23.0*
108*
—
25.5*
109,108
—
UNIT
558F
VOLTAGE
(60 Hz)
ACCESSORY
kW
ACCESSORY
HEATER
PART NUMBER
CRHEATER---A00
ACCESSORY
SINGLE POINT BOX
PART NO.
CRSINGLE---A00
090,
102
208/230
(3 phase)
10.5
117
006
16.0
110
006
24.8
111
007
32.0
112
007
42.4*
112,117
007†
460
(3 phase)
14.0
116
006
16.5
113
006
27.8
114
006
33.0
115
006
41.7*
114,116
008
575
(3 phase)
17.0
118
006
34.0
119
006
120,
150
208/230
(3 phase)
10.5
117
012
16.0
110
012
32.0
112
012
42.4*
112,117
015
50.0*
112,110
015
460
(3 phase)
16.5
113
011
27.8
114
011
33.0
115
011**
41.7*
114,116
014
50.0*
115,113
014
575
(3 phase)
17.0
118
011
34.0
119
011
51.0*
119,118
014
HEATER kW
RATING
VOLTAGE DISTRIBUTION
V/3/60
MULTIPLICATION
FACTOR
240
200
208
230
240
.69
.75
.92
1.00
480
440
460
480
.84
.92
1.00
600
550
575
600
.84
.92
1.00
