Bryant
Airconditioning I
Company
installation instructions
MANUAL OUTSIDE
AIR DAMPER PACKAGE
Cancels; 39579D75
559C
579C
599C
Sizes
090 thru 360
39579DP92
6/1/74
These instructions cover the installation of the manual out
side air damper package on sizes 090 through 360 of Models
559C, 579C, and 599C. The manual outside air damper
package
consists
of
an
adjustable
damper
factory-as
sembled in a rainhood and birdscreen assembly (air intake
box)
Table I lists the components of each package and the pack
age part number for each size of all modells. Refer to Figure
1 for air intake box dimensions. The unit opening (dimen
sions D and E) for intake of outside air is also shown in
Figure 1.
Size Used On
A
B
C
D
E
F
G
090 & 120
39-5/16
27-9/16
12
39
11-1/2
10-1/2
37-13/16
180
48-5/16
30-9/16
12
48
13-1/2
10-1/2
46-13/16
240
69-5/16
30-9/16
12
69-1/16
18-1/16
10-1/2
67-13/16
300 & 360
69-5/16
38-9/16
12
69-1/16
18-1/16
10-1/2
67-13/16
Figure 1—Air intake Box Dimensions
TABLE I—MANUAL OUTSiDE AIR DAMPER PACKAGES
Package Contents
P/N
Package P/N and Size Used on
090 & 120
P/N 71787D01
180
P/N 71787D02
240
P/N 71787D0O5
300 & 360
P/N 71787D0O7
Air Intake Box Assembly
71965B01
1
Air Intake Box Assembly
71965B02
1
Air Intake Box Assembly
71965B0O5
1
Air Intake Box Assembly
71965B0O6
1
Screw
FAJ6010B
6
7
9
9
Installation Instructions
39579DP92
1
1
1
1
