ELECTRICAL DATA (cont)
HIGH-STATIC MOTOR UNITS WITHOUT ELECTRICAL CONVENIENCE OUTLET
NOTE: See legend and notes on page 97.
UNIT
NOMINAL
VOLTAGE
(V-Ph-Hz)
VOLTAGE
RANGE
COMPRESSOR
(each)
OFM
IFM
ELECTRIC HEAT
POWER SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE*
Min
Max
RLA
LRA
FLA
FLA
Nominal
kW†
FLA
MCA
MOCP
FLA
LRA
551B036
208/230-3-60
187
254
10.3
77.0
0.7
5.8
—
3.3/ 4.4
4.9/ 6.5
6.5/ 8.7
7.9/10.5
12.0/16.0
—
9.2/10.6
13.6/15.6
18.1/20.9
21.9/25.3
33.4/38.5
19.4/19.4
19.4/20.5
24.2/26.8
29.9/33.4
34.6/38.8
48.9/55.4
25/25
25/25
30/30
35/35
35/40
50/60
19/19
19/19
22/25
28/31
32/36
45/51
120/120
460-3-60
414
508
5.1
39.0
0.4
2.6
—
6.0
8.8
11.5
14.0
—
7.2
10.6
13.8
16.8
9.4
12.3
16.5
20.5
24.3
15
15
20
25
25
9
11
15
19
22
60
575-3-60
518
632
4.2
31.0
0.4
2.6
—
—
7.7
15
8
52
551B048
208/230-3-60
187
254
13.5
99.0
0.7
5.8
—
4.9/ 6.5
6.5/ 8.7
12.0/16.0
15.8/21.0
—
13.6/15.6
18.1/20.9
33.4/38.5
43.8/50.5
23.4/23.4
24.2/26.8
29.9/33.4
48.9/55.4
62.0/70.4
30/30
30/30
35/35
50/60
70/80**
23/23
23/25
28/31
45/51
57/65
142/142
460-3-60
414
508
7.4
49.5
0.4
2.6
—
6.0
11.5
14.0
23.0
—
7.2
13.8
16.8
27.7
12.3
12.3
20.5
24.3
37.8
15
15
25
25
40
12
12
19
22
35
70
575-3-60
518
632
5.8
40.0
0.4
2.6
—
—
9.7
15
9
57
551B060
208/230-3-60
187
254
17.3
123.0
1.5
7.5
—
4.9/ 6.5
7.9/10.5
12.0/16.0
15.8/21.0
19.9/26.5
—
13.6/15.6
21.9/25.3
33.4/38.5
43.8/50.5
55.2/63.8
30.6/30.6
30.6/30.6
36.7/40.9
51.1/57.5
64.1/72.5
78.4/89.1
35/35
35/35
40/45
60/60
70/80**
80/90**
30/30
30/30
34/38
47/53
59/67
72/82
187/187
460-3-60
414
508
9.0
62.0
0.8
3.4
—
6.0
11.5
14.0
23.0
25.5
—
7.2
13.8
16.8
27.7
30.1
15.5
15.5
21.5
25.3
38.8
41.8
20
20
25
30
40
45
15
15
20
23
36
38
93
575-3-60
518
632
7.1
50.0
0.8
3.4
—
—
12.2
15
12
75
551B072
208/230-3-60
187
254
20.5
156.0
1.4
7.5
—
4.9/ 6.5
7.9/10.5
12.0/16.0
15.8/21.0
19.9/26.5
—
13.6/15.6
21.9/25.3
33.4/38.5
43.8/50.5
55.2/63.8
30.6/30.6
34.5/34.5
36.7/40.9
51.1/57.5
64.1/72.5
78.4/89.1
35/35
40/40
45/45
60/60
70/80**
80/90**
30/30
34/34
34/38
47/53
59/67
72/82
219/219
460-3-60
414
508
9.6
70.0
0.6
3.4
—
6.0
11.5
14.0
23.0
25.5
—
7.2
13.8
16.8
27.7
30.7
15.5
16.0
21.5
25.3
38.8
42.6
20
20
25
30
40
45
15
16
20
23
36
39
101
575-3-60
518
632
7.7
56.0
0.6
3.4
—
—
12.2
15
12
76
