61
PERFORMANCE DATA (cont)
ACCESSORY/FIOP STATIC PRESSURE (in. wg) — 558F036-073
LEGEND
FIOP — Factory-Installed Option
*The static pressure must be added to external static pressure. The sum and the evaporator
entering-air cfm should then be used in conjunction with the Fan Performance tables to deter-
mine blower rpm and watts.
ACCESSORY/FIOP STATIC PRESSURE* (in. wg) — 558F090-150
LEGEND
FIOP — Factory-Installed Option
*The static pressure must be added to external static pressure. The sum and the evaporator
entering-air cfm should then be used in conjunction with the Fan Performance tables to deter-
mine blower rpm and watts.
FAN RPM AT MOTOR PULLEY SETTINGS*
*Approximate fan rpm shown.
†Indicates alternate motor and drive package.
**Indicates high-static motor and drive package.
††Indicates standard motor and drive package.
***Indicates alternate drive package only.
COMPONENT
CFM
900 1200 1400 1600 1800 2000 2200 2400 2600 3000
1 Heater Module 0.05 0.07 0.09 0.09 0.10 0.11 0.11 0.12 0.13 0.15
2 Heater Modules 0.15 0.16 0.16 0.16 0.17 0.17 0.17 0.18 0.18 0.19
EconoMi$er 0.05 0.09 0.13 0.17 0.22 0.27 0.32 0.39 0.45 0.53
COMPONENT
CFM
2250 2500 3000 3500 4000 4500 5000 5500 6000 6250
1 Heater Module 0.02 0.03 0.05 0.07 0.08 0.10 0.12 0.14 0.16 0.17
2 Heater Modules 0.03 0.05 0.07 0.09 0.12 0.14 0.16 0.19 0.21 0.20
EconoMi$er 0.07 0.09 0.13 0.18 0.23 0.30 0.36 — — —
UNIT 558F
MOTOR PULLEY TURNS OPEN
0 1 /
2
1 1 1 /
2
2 2 1 /
2
3 3 1 /
2
4 4 1 /
2
5 5 1 /
2
6
036† 1000 976 952 928 904 880 856 832 808 784 760 — —
036** 1455 1423 1392 1360 1328 1297 1265 1233 1202 1170 1138 1107 1075
048† 1185 1150 1115 1080 1045 1010 975 940 905 870 835 — —
048** 1455 1423 1392 1360 1328 1297 1265 1233 1202 1170 1138 1107 1075
060† 1300 1260 1220 1180 1140 1100 1060 1020 980 940 900 — —
060** 1685 1589 1557 1525 1493 1460 1428 1396 1364 1332 1300 — —
072,073†† 1460 1420 1380 1345 1305 1265 1225 1185 1150 1110 1070 — —
072,073** 1685 1589 1557 1525 1493 1460 1428 1396 1364 1332 1300 — —
090,091†† 840 815 790 765 740 715 690 665 635 615 590 — —
090,091*** 935 910 885 860 835 810 785 760 735 710 685 — —
090,091** 1080 1025 1007 988 970 952 933 915 897 878 860 — —
102†† 935 910 885 860 835 810 785 760 735 710 685 — —
102** 1080 1025 1007 988 970 952 933 915 897 878 860 — —
120,121†† 935 910 885 860 835 810 785 760 735 710 685 — —
120,121† 1085 1060 1035 1010 985 960 935 910 885 860 835 — —
120,121** 1130 1112 1087 1062 1037 1012 987 962 937 912 887 862 830
150†† 1080 1060 1035 1015 990 970 950 925 905 880 860 — —
150† 1260 1220 1185 1155 1130 1100 1075 1045 1015 990 960 930 900
