Bryant DURAPAC 551B - Manual (Page 127)

127
ELECTRICAL DATA
See Legend and Notes on page 128.
UNIT
559F
NOMINAL
VOLTAGE
(3 Ph, 60 Hz)
VOLTAGE
RANGE
COMPRESSOR
OFM IFM POWER
EXHAUST
ELECTRIC
HEAT*
POWER
SUPPLY No. 1 No. 2
Min Max RLA LRA RLA LRA Qty Hp FLA (ea) Hp FLA FLA LRA kW FLA MCA MOCP†
180
(15 Tons)
208/230 187 253 28.8 195 28.8 195 3 0.5 1.7 3.7 10.5/11.0
— — — — 81/ 81 100/100
4.6 18.8 — — 85/ 86 110/110
— — 26/34 71/ 82 102/116 110/125
4.6 18.8 26/34 71/ 82 108/122 110/125
— — 42/56 117/135 159/149 175/175
4.6 18.8 42/56 117/135 165/155 175/175
— — 56/75 156/180 169/194 200/225
4.6 18.8 56/75 156/180 175/200 200/225
460 414 508 14.7 95 14.7 95 3 0.5 0.8 3.7 4.8
— — — — 40 50
2.3 6.0 — — 43 50
— — 32 39 55 60
2.3 6.0 32 39 58 60
— — 55 66 72 80
2.3 6.0 55 66 75 80
— — 80 96 102 110
2.3 6.0 80 96 105 110
216
(18 Tons)
208/230 187 253 30.1 225 28.8 195 3 0.5 1.7 5.0 15.8/15.8
— — — — 87/ 87 110/110
4.6 18.8 — — 92/ 92 110/110
— — 26/34 71/ 82 109/122 110/125
4.6 18.8 26/34 71/ 82 114/128 125/150
— — 42/56 117/135 166/155 175/175
4.8 18.8 42/56 117/135 172/161 175/175
— — 56/75 156/180 176/200 200/225
4.6 18.8 56/75 156/180 182/206 200/225
460 414 508 15.5 114 14.7 95 3 0.5 0.8 5.0 7.9
— — — — 44 50
2.3 6.0 — — 47 60
— — 32 39 59 60
2.3 6.0 32 39 61 70
— — 55 66 76 90
2.3 6.0 55 66 79 90
— — 80 96 106 125
2.3 6.0 80 96 109 125
240
(20 Tons)
208/230 187 253 37.8 239 30.1 225 2 1 6.6 7.5 25.0/25.0
— — — — 116/116 150/150
4.6 18.8 — — 120/120 150/150
— — 26/34 71/ 82 120/134 150/150
4.6 18.8 26/34 71/ 82 126/140 150/150
— — 42/56 117/135 178/166 200/175
4.6 18.8 42/56 117/135 183/172 200/175
— — 56/75 156/180 187/211 200/225
4.6 18.8 56/75 156/180 193/217 200/225
460 414 508 17.2 125 15.5 114 2 1 3.3 7.5 13.0
— — — — 57 70
2.3 6.0 — — 59 70
— — 32 39 65 70
2.3 6.0 32 39 68 70
— — 55 66 82 90
2.3 6.0 55 66 85 90
— — 80 96 112 125
2.3 6.0 80 96 115 125
300
(25 Tons)
208/230 187 253 41.0 350 37.8 239 2 1 6.6 10.0 28.0/28.0
— — — — 130/130 150/150
4.6 18.8 — — 135/135 175/175
— — 26/34 71/ 82 130/138 150/150
4.6 18.8 26/34 71/ 82 135/143 175/175
— — 42/56 117/135 181/170 200/175
4.6 18.8 42/56 117/135 187/176 200/200
— — 56/75 156/180 191/215 200/225
4.6 18.8 56/75 156/180 197/221 200/225
460 414 508 21.8 158 17.2 125 2 1 2.8 10.0 14.6
— — — — 66 80
2.3 6.0 — — 68 80
— — 32 39 67 80
2.3 6.0 32 39 70 80
— — 55 66 84 90
2.3 6.0 55 66 87 100
— — 80 96 114 125
2.3 6.0 80 96 117 125
