155
ACCESSORY DIMENSIONS (cont)
2'-1 5/8"
2'-2 1/16"
1'-6 5/16"
Horizontal Supply/Return Adapter Installation
NOTE: CRRFCURB013A00 is a fully factory preassembled horizontal
adapter and includes an insulated high static regain transition duct
which substantially improves fan static performance.
The Barometric Relief Damper and Power Exhaust accessories are
not available with the horizontal adapter.
ACCESSORY
PACKAGE NO.
CURB
HEIGHT
DESCRIPTION
CRRFCURB013A00
2 ′′′′-0″″″″
(610)
Pre-Assembled, High Static,
Horizontal Adapter Roof Curb
Barometric Relief/Power Exhaust
0
T
F
Q
0
04
-0
12
55
1A1
55-
18
0
