ELECTRICAL DATA — 558F036-073
See Legend and Notes on page 70.
UNIT
558F NOMINAL
V-Ph-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(ea)
OFM
(ea) IFM
FLA
ELECTRIC
HEAT*
POWER
SUPPLY
DISCONNECT
SIZE†
Min Max RLA LRA Qty Hp FLA
Nominal
kW**
FLA MCA MOCP†† FLA LRA
036
208/230-1-60
Std
187 254 16.2 96.0 1 1 /
4
1.4
3.5
— — 25.2/25.2 30/30 24/24
106/106
3.3/ 4.4 15.9/18.3 25.2/27.3 30/30 24/25
4.9/ 6.5 23.5/27.1 33.1/38.2 35/40 31/35
6.5/ 8.7 31.4/36.3 43.6/49.7 45/50 40/46
7.9/10.5 37.9/43.8 51.5/59.1 60/60 48/54
9.8/13.0 46.9/54.2 63.0/72.1 70/80|| 58/66
Alt 4.9
— — 26.6/26.6 35/35 26/26
111/111
3.3/ 4.4 15.9/18.3 26.6/29.0 35/35 26/27
4.9/ 6.5 23.5/27.1 35.5/40.0 40/40 33/37
6.5/ 8.7 31.4/36.3 45.4/51.4 50/60 42/47
7.9/10.5 37.9/43.8 53.5/60.8 60/70|| 49/56
9.8/13.0 46.9/54.2 64.8/73.8 70/80|| 60/68
208/230-3-60
Std
187 254 10.2 75.0 1 1 /
4
1.4
3.5
— — 17.7/17.7 25/25 17/17
85/85
3.3/ 4.4 9.2/10.6 17.7/17.7 25/25 17/17
4.9/ 6.5 13.6/15.6 21.3/23.9 25/25 20/22
6.5/ 8.7 18.1/20.9 27.0/30.5 30/35 25/28
7.9/10.5 21.9/25.3 31.7/35.9 35/40 29/33
12.0/16.0 33.4/38.5 46.1/52.5 50/60 42/48
Alt 4.9
— — 19.1/19.1 25/25 19/19
90/90
3.3/ 4.4 9.2/10.6 19.1/19.4 25/25 19/19
4.9/ 6.5 13.6/15.6 23.1/25.7 25/30 21/24
6.5/ 8.7 18.1/20.9 28.8/32.3 30/35 26/30
7.9/10.5 21.9/25.3 33.5/37.7 35/40 31/35
12.0/16.0 33.4/38.5 46.1/52.5 50/60 42/48
High 5.2
— — 19.4/19.4 25/25 19/19
109/109
3.3/ 4.4 9.2/10.6 19.4/19.7 25/25 19/19
4.9/ 6.5 13.6/15.6 23.4/26.0 30/30 22/24
6.5/ 8.7 18.1/20.9 29.2/32.7 30/35 27/30
7.9/10.5 21.9/25.3 33.9/38.1 35/40 31/35
12.0/16.0 33.4/38.5 48.2/54.6 50/60 44/50
460-3-60
Std
414 508 4.4 40.0 1 1 /
4
0.8
1.3
— — 7.6 15 7
44/44
6.0 7.2 10.6 15 10
8.8 10.6 14.9 15 14
11.5 14.0 18.9 20 17
14.0 17.0 22.7 25 21
Alt 2.1
— — 8.4 15 8
48/48
6.0 7.2 11.6 15 11
8.8 10.6 15.9 20 15
11.5 14.0 19.9 20 18
14.0 17.0 23.7 25 22
High 2.6
— — 8.9 15 9
57/57
6.0 7.0 12.3 15 11
8.8 11.0 16.5 20 15
11.5 14.0 20.5 25 19
14.0 17.0 24.3 25 22
575-3-60
Std
518 632 3.7 31.0 1 1 /
4
0.8
1.3 — — 6.7 15 7 35
Alt 2.1 — — 7.5 15 8 39
High 2.6 — — 8.0 15 8 63
048
208/230-1-60
Std
187 254 23.3 118.0 1 1 /
4
1.4
3.5
— — 34.0/ 34.0 40/ 40 32/ 32
129/129
3.3/ 4.4 15.9/18.3 34.0/ 34.0 40/ 40 32/ 32
6.5/ 8.7 31.4/36.3 43.6/ 49.7 45/ 50 40/ 46
9.8/13.0 46.9/54.2 63.0/ 72.1 70/ 80|| 58/ 66
13.1/17.4 62.8/72.5 82.9/ 95.0 90/100|| 76/ 87
16.0/21.0 75.8/87.5 99.2/113.8 100/125|| 91/105
Alt 4.9
— — 35.4/ 35.4 45/ 45 34/ 34
133/133
3.3/ 4.4 15.9/18.3 35.4/ 35.4 45/ 45 34/ 34
6.5/ 8.7 31.4/36.3 45.4/ 51.4 50/ 60 42/ 47
9.8/13.0 46.9/54.2 64.8/ 73.8 70/ 80|| 60/ 68
13.1/17.4 62.8/72.5 84.7/ 96.8 90/100|| 78/ 89
16.0/21.0 75.8/87.5 100.9/115.5 110/125|| 93/106
208/230-3-60
Std
187 254 15.4 90.0 1 1 /
4
1.4
3.5
— — 24.2/24.2 30/30 23/23
101/101
4.9/ 6.5 13.6/15.6 24.2/24.2 30/30 23/23
6.5/ 8.7 18.1/20.9 27.0/30.5 30/35 25/28
12.0/16.0 33.4/38.5 46.1/52.5 50/60 42/48
16.0/21.0 43.8/50.5 59.1/67.5 60/70|| 54/62
Alt 4.9
— — 25.6/25.6 30/30 25/25
105/105
4.9/ 6.5 13.6/15.6 25.6/25.7 30/30 26/26
6.5/ 8.7 18.1/20.9 28.8/32.3 30/35 26/30
12.0/16.0 33.4/38.5 47.8/54.2 50/60 44/50
16.0/21.0 43.8/50.5 60.8/69.3 70/70|| 56/64
High 5.2
— — 25.9/25.9 30/30 25/25
124/124
4.9/ 6.5 13.6/15.6 25.9/26.0 30/30 25/25
6.5/ 8.7 18.1/20.9 29.2/32.7 30/35 27/30
12.0/16.0 33.4/38.5 48.2/54.6 50/60 44/50
16.0/21.0 43.8/50.5 61.2/69.6 70/70|| 56/64
