109
MODEL NUMBER NOMENCLATURE — 559F
ARI* CAPACITY RATINGS
LEGEND
*Air Conditioning and Refrigeration Institute.
NOTES:
1. Rated in accordance with ARI Standards 360-89 and 270-89.
2. The 559F300 is beyond the scope of the ARI Certification
Program.
3. ARI ratings are net values, reflecting the effects of circulating fan
heat.
4. Ratings are based on:
Cooling Standard: 80 F db, 67 F wb indoor entering-air tempera-
ture and 95 F db air entering outdoor unit.
IPLV Standard: 80 F db, 67 F wb indoor entering-air temperature
and 80 F db outdoor entering-air temperature.
5. These units do not comply with ASHRAE 90.1-1999 efficiency
requirements.
AIR QUANTITY LIMITS LOW OUTDOOR TEMPERATURE
OPERATING LIMITS (F)
UNIT
559F NOMINAL
TONS
STANDARD
CFM
NET COOLING
CAPACITY
(Btuh)
TOTAL
WATTS
EER
SOUND
RATING
(dB)
IPLV
180 15 5250 176,000 19,813 8.9 88 9.6
216 18 6200 188,000 21,298 8.8 88 9.8
240 20 6600 220,000 25,146 8.7 95 8.9
300 25 7200 268,000 30,858 8.7 95 9.3
dB — Sound Levels (decibels)
db — Dry Bulb
EER — Energy Efficiency Ratio
IPLV — Integrated Part-Load Values
wb
— Wet Bulb
UNIT 559F MINIMUM CFM MAXIMUM CFM
180 4500 7,500
216 5400 9,000
240 6000 10,000
300 7000 11,250
UNITS TEMPERATURE
All 40
180 and 216 with Low Ambient Kit 10
240 and 300 with Low Ambient Kit 25
All with Head Pressure Control –20
Nominal Tons
180 – 15
216 – 18
240 – 20
300 – 25
559F – Standard Efficiency
Electric Cooling Unit Fan Drive Position
(Standard Motor)
B – Standard Low-Medium
Fan Drive Static Capability
D – Alternate High Fan Drive
Static Capability
Voltage Designation
E – 460-3-60
P – 208/230-3-60
Electric Heaters
000 – No factory-installed electric heaters
Heat Type
X – No Heat Installed
(Field-installed electric heaters available)
Factory-Installed
Outdoor Air and Other
Upgrade Options
C – EconoMi$er
H – Manual Outdoor-Air Damper
Design Series Code
AH – Original Design Series
5 5 9 F E X 1 8 0 0 0 0 A H C B
NOTE: The example model number 559FEX180000AHCB designates a 15-ton 460-3-60 volt electric cooling rooftop unit with scroll compressors,
TXVs, EconoMi$er and the standard low-medium fan drive static capability.
