130
ARI* CAPACITY RATINGS (cont)
ELECTRIC RESISTANCE HEATER DATA — 558F180-300
*Maximum number of stages using accessory low-ambient kit or head pressure control device and low-ambient kit.
NOTE: Heaters are rated at 240, 480, and 600 v. Use the Multiplication Factors table below to determine heater capacity
for your particular voltage.
MULTIPLICATION FACTORS
NOTE: The following equation converts kW of heat energy to Btuh:
kW x 3.413 = Btuh. EXAMPLE: 34 kW (at 230 v) heater on 208 v
= 34.0 (.751 mult factor)
= 25.5 kW capacity at 208 v.
UNIT
558F
HEATER kW
HEATER
STAGES HEAT
PER STAGE
MAXIMUM
STAGES*
MINIMUM
HEATING CFM Unit Voltages
208 230 460 575 Cfm L/s
180
26 31 30 — 2 50/50 2
3750 1770 42 52 50 — 2 33/67 3
56 69 73 — 2 50/50 4
210
26 34 32 — 2 50/50 2
5400 2549 42 56 55 — 2 33/67 3
56 75 80 — 2 50/50 4
240
26 31 30 — 2 50/50 2
5000 2360 42 52 50 — 2 33/67 3
56 69 73 — 2 50/50 4
300
26 34 32 — 2 50/50 2
7000 3304 42 56 55 — 2 33/67 3
56 75 80 — 2 50/50 4
HEATER RATING
VOLTAGE
ACTUAL HEATER VOLTAGE
200 208 230 240 380 440 460 480 550 575 600
240 0.694 0.751 0.918 1.000 — — — — — — —
480 — — — — 0.626 0.840 0.918 1.000 — — —
600 — — — — — — — — 0.840 0.918 1.000
