140
PERFORMANCE DATA (cont)
COOLING CAPACITIES
558F180 (15 TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
4,500/0.010 5,250/0.120 6,000/0.140 6,750/0.150 7,500/0.160
Air Entering Evaporator — Ewb (F)
62 67 72 62 67 72 62 67 72 62 67 72 62 67 72
75
TC 175.7 191.8 210.9 180.5 196.4 214.9 183.3 201.0 218.9 187.1 203.0 222.9 189.2 205.0 224.9
SHC 145.5 123.0 99.9 156.2 131.5 104.9 167.8 139.1 110.6 175.3 146.3 115.0 183.7 155.8 119.4
kW 14.0 14.4 15.0 14.2 14.6 15.1 14.3 14.7 15.2 14.4 14.9 15.4 14.5 14.9 15.4
85
TC 168.8 185.1 203.0 173.3 189.2 207.0 177.1 192.8 210.9 179.7 196.0 214.9 182.3 198.0 216.9
SHC 141.7 119.8 97.1 151.6 128.6 101.9 162.4 135.9 106.7 171.1 143.1 111.0 179.1 150.2 116.4
kW 15.2 15.6 16.1 15.3 15.8 16.3 15.5 15.9 16.5 15.6 16.1 16.6 15.7 16.1 16.7
95
TC 161.8 177.5 194.4 166.4 181.5 199.0 169.0 184.7 203.0 171.7 187.7 205.0 174.5 189.4 207.0
SHC 138.7 116.8 93.9 147.5 125.2 99.1 157.6 132.7 103.3 167.2 139.9 108.3 173.9 146.5 112.2
kW 16.4 16.9 17.4 16.6 17.0 17.6 16.7 17.2 17.7 16.8 17.3 17.8 16.9 17.4 17.9
105
TC 154.6 169.3 185.3 158.6 173.1 189.2 161.2 175.9 192.0 164.0 178.1 194.6 167.4 179.7 196.2
SHC 133.9 113.6 90.7 143.7 121.4 95.7 154.2 129.0 100.3 161.8 136.1 104.7 167.2 142.7 108.7
kW 17.6 18.2 18.7 17.8 18.3 18.8 17.9 18.5 18.9 18.1 18.5 19.1 18.2 18.6 19.1
115
TC 147.1 160.8 175.5 150.4 164.2 179.1 152.4 166.4 181.9 155.8 168.6 184.3 159.6 169.7 185.7
SHC 130.1 110.2 87.4 139.7 117.8 92.1 149.3 125.4 96.7 155.6 131.9 101.1 159.2 139.1 105.3
kW 19.0 19.5 20.0 19.1 19.7 20.2 19.2 19.8 20.2 19.4 19.9 20.4 19.5 19.9 20.4
118
TC 144.7 158.0 172.5 147.7 161.2 175.9 150.0 163.4 178.3 153.4 165.4 180.7 157.0 166.8 182.1
SHC 129.0 109.1 86.4 138.5 116.6 91.1 147.7 124.2 95.5 153.4 130.7 99.9 156.8 137.7 104.1
kW 19.4 19.9 20.4 19.5 20.0 20.6 19.6 20.2 20.6 19.8 20.2 20.8 19.9 20.4 20.8
120
TC 142.9 156.2 170.5 145.9 159.2 — 148.3 161.2 — 151.8 163.2 — 155.4 164.8 —
SHC 128.0 108.0 86.0 138.0 116.0 — 146.0 123.0 — 152.0 130.0 — 155.0 137.0 —
kW 19.6 20.2 20.6 19.8 20.2 — 19.9 20.4 — 20.0 20.4 — 20.2 20.6 —
558F210 (18 TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air Quantity — Cfm/BF
5,400/0.095 6,000/0.105 7,000/0.120 8,000/0.140 9,000/0.150
Evaporator Air — Ewb (F)
62 67 72 62 67 72 62 67 72 62 67 72 62 67 72
75
TC 227 247 269 232 251 274 237 255 277 241 258 280 248 261 283
SHC 200 167 134 215 178 141 231 194 152 241 205 160 248 219 167
kW 15.9 16.5 17.2 16.1 16.7 17.3 16.3 16.8 17.5 16.5 16.9 17.6 16.7 17.0 17.7
85
TC 219 238 259 224 242 265 229 247 269 235 250 272 241 252 273
SHC 197 164 131 210 175 137 225 188 145 234 200 153 240 214 163
kW 17.2 17.8 18.5 17.4 17.9 18.6 17.6 18.1 18.8 17.8 18.3 19.0 18.0 18.3 19.0
95
TC 210 229 248 214 233 253 219 237 258 225 239 261 231 242 263
SHC 192 160 126 205 171 133 218 183 141 225 194 148 231 206 156
kW 18.5 19.2 19.9 18.7 19.3 20.0 19.0 19.5 20.2 19.2 19.6 20.3 19.4 19.7 20.4
105
TC 200 218 237 205 222 241 210 225 245 216 228 249 221 230 250
SHC 186 155 123 199 166 129 210 178 136 216 190 143 221 201 150
kW 19.9 20.5 21.2 20.1 20.7 21.3 20.4 20.8 21.5 20.6 21.0 21.7 20.8 21.0 21.8
115
TC 190 207 225 195 210 228 201 213 232 206 216 235 211 217 236
SHC 181 151 118 193 161 124 201 173 132 206 185 139 211 196 146
kW 21.3 21.9 22.6 21.5 22.1 22.8 21.8 22.2 22.9 22.0 22.4 23.1 22.2 22.4 23.1
120
TC 185 200 218 189 205 221 196 207 225 201 209 227 205 210 229
SHC 179 149 117 189 159 122 196 171 130 201 182 137 205 193 144
kW 22.1 22.6 — 22.3 22.8 — 22.5 22.9 — 22.7 — — 22.9 — —
558F240 (20 TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Evaporator Air Quantity — Cfm/BF
6,000/0.04 7,000/0.05 8,000/0.06 9,000/0.07 10,000/0.08
Evaporator Air — Ewb (F)
62 67 72 62 67 72 62 67 72 62 67 72 62 67 72
75
TC 237 258 282 242 264 288 247 268 291 252 271 295 258 274 298
SHC 204 171 138 221 184 146 237 199 156 247 210 164 257 221 172
kW 16.7 17.4 18.1 16.9 17.6 18.3 17.1 17.8 18.5 17.3 17.9 18.6 17.5 18.0 18.7
85
TC 229 249 272 234 254 278 239 260 283 245 262 286 250 265 287
SHC 201 167 135 216 180 142 231 193 150 240 203 157 250 217 167
kW 18.1 18.7 19.5 18.3 18.9 19.7 18.5 19.1 19.9 18.7 19.3 20.1 18.8 19.4 20.1
95
TC 220 239 261 225 245 267 230 249 271 235 251 275 241 255 277
SHC 195 163 130 211 176 138 224 188 145 233 199 152 241 210 160
kW 19.4 20.2 20.9 19.7 20.4 21.2 19.9 20.6 21.3 20.1 20.6 21.4 20.3 20.8 21.6
105
TC 209 228 249 216 234 254 220 237 259 225 240 262 230 242 263
SHC 189 159 126 206 171 134 217 183 140 225 195 148 230 205 154
kW 20.9 21.5 22.3 21.2 21.8 22.5 21.4 22.0 22.7 21.6 22.1 22.9 21.8 22.2 23.0
115
TC 200 217 237 205 222 241 211 225 244 216 227 248 221 229 249
SHC 185 154 122 199 166 129 209 178 136 216 189 143 221 200 150
kW 22.5 23.1 23.8 22.7 23.3 24.0 22.9 23.4 24.2 23.2 23.6 24.4 23.4 23.7 24.4
120
TC 194 211 230 199 216 234 205 218 237 210 220 240 214 222 241
SHC 183 152 121 195 164 126 204 175 134 210 186 141 214 196 148
kW 23.2 23.8 24.6 23.5 24.0 — 23.7 24.2 — 23.9 24.4 — 24.1 24.4 —
