PERFORMANCE DATA (cont
COOLING CAPACITIES (cont))
558F091 (7
1
/
2
TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
2250/0.10
2800/0.11
3000/0.11
3750/0.14
Air Entering Evaporator — Ewb (F)
72
67
62
72
67
62
72
67
62
72
67
62
75
TC
104.8
96.6
87.9
107.8
100.1
91.7
108.4
100.9
92.5
111.3
103.6
95.4
SHC
50.4
63
74.6
53.6
69.1
83.2
54.6
71.1
85.6
59.3
78.9
94
kW
6.34
6.05
5.77
6.46
6.19
5.93
6.5
6.25
5.96
6.62
6.37
6.09
85
TC
100.1
91.9
83.2
103.8
95.4
86.8
104.6
96.2
87.7
106.6
98.7
91.3
SHC
48.9
61.4
72.6
52.6
67.7
81.1
53.8
69.9
83.6
57.9
77.5
91.1
kW
6.8
6.51
6.21
6.94
6.66
6.37
6.98
6.69
6.41
7.08
6.82
6.57
95
TC
95.6
86.8
78.1
98.9
90.1
81.5
99.5
90.7
82.8
101.3
93
86.8
SHC
47.3
59.3
70.1
51.2
65.8
78.7
52.4
68.1
80.5
56.7
75.8
86.8
kW
7.26
6.96
6.64
7.42
7.1
6.78
7.46
7.14
6.83
7.54
7.24
7.03
105
TC
90.1
81.3
72.2
92.8
84.4
76
93.4
85
77.5
95.6
87
82.2
SHC
45.5
57.3
67.3
49.1
63.8
75.6
50.4
66
77.1
55.2
73.8
82.2
kW
7.7
7.37
7.08
7.81
7.51
7.22
7.86
7.54
7.28
7.97
7.67
7.47
115
TC
84.4
75.2
67.3
86.8
78.3
70.9
87.2
78.9
72.4
89.3
80.9
77.5
SHC
43.4
54.8
64.4
47.3
61.6
70.9
48.7
63.8
72.4
53.8
71.8
77.3
kW
8.13
7.79
7.47
8.25
7.92
7.67
8.29
7.95
7.74
8.41
8.08
7.93
558F102 (8
1
/
2
TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
2550/0.08
3000/0.10
3400/0.11
4250/0.135
Air Entering Evaporator — Ewb (F)
72
67
62
72
67
62
72
67
62
72
67
62
75
TC
116.6
108.4
99.0
119.2
111.3
101.8
120.1
112.8
103.6
122.3
114.8
106.3
SHC
71.9
61.9
75.9
75.2
65.1
81.4
80.5
68.0
85.6
32.7
73.9
94.4
kW
7.77
7.57
7.38
7.86
10.68
7.44
7.89
6.72
7.51
7.97
7.80
7.60
85
TC
113.3
104.2
94.0
115.7
106.9
97.0
117.2
108.7
98.8
120.1
111.0
101.8
SHC
54.0
67.7
80.4
56.3
72.5
87.1
58.2
76.4
92.5
62.9
84.2
101.0
kW
8.46
8.22
7.96
5.54
8.31
8.04
8.60
8.38
8.12
8.72
8.48
8.23
95
TC
109.1
99.3
87.3
111.2
102.0
91.4
112.5
103.6
93.7
115.3
105.8
107.4
SHC
52.6
65.9
77.4
55.0
70.9
84.9
57.1
75.1
90.3
62.2
83.2
97.3
kW
8.90
8.97
8.68
8.99
9.06
8.79
9.06
9.12
8.86
4.76
9.24
9.00
105
TC
103.3
94.0
81.4
105.9
96.3
84.6
107.4
97.7
87.9
109.4
99.9
92.8
SHC
50.5
54.0
74.5
53.5
69.1
81.4
55.8
73.1
86.6
60.4
81.4
92.8
kW
9.74
9.43
9.08
9.85
9.54
9.21
9.92
9.60
9.29
10.03
9.72
9.48
115
TC
97.7
87.9
75.9
99.9
90.4
78.8
101.3
91.8
82.4
102.9
93.8
88.3
SHC
48.7
61.7
71.9
51.8
66.9
78.1
54.0
71.2
82.3
58.5
79.4
88.2
kW
10.33
9.97
9.61
10.46
10.10
9.75
10.54
10.18
9.88
10.61
10.30
10.10
558F120 (10 TONS)
Temp (F)
Air Entering
Condenser
(Edb)
Air Entering Evaporator — Cfm/BF
3000/0.095
4000/0.125
5000/0.15
Air Entering Evaporator — Ewb (F)
72
67
62
72
67
62
72
67
62
75
TC
135.8
124.8
112.0
142.4
130.6
119.8
146.5
134.2
123.7
SHC
66.8
82.6
97.4
73.2
93.4
112.7
79.7
104.4
123.1
kW
9.76
9.41
9.10
10.00
9.61
9.27
10.17
9.75
9.41
85
TC
130.0
119.6
104.0
136.0
125.0
114.5
140.0
127.9
118.8
SHC
64.3
80.5
93.8
71.1
91.7
110.2
77.5
101.8
118.7
kW
10.41
10.07
9.74
10.67
10.28
9.94
10.84
10.41
10.09
95
TC
124.1
113.7
96.7
129.5
118.9
106.9
132.8
122.0
114.1
SHC
62.2
78.4
90.0
69.1
89.8
105.9
74.9
100.1
114.0
kW
11.13
10.78
10.40
11.38
10.99
10.63
11.52
11.14
10.83
105
TC
118.1
104.6
87.9
122.7
111.8
98.5
126.0
115.1
108.0
SHC
60.4
74.9
85.2
66.9
87.7
98.5
73.1
98.3
108.0
kW
11.93
11.52
11.10
12.13
11.74
11.41
12.27
11.89
11.65
115
TC
115.0
98.0
84.2
120.0
103.8
93.4
122.6
109.8
102.8
SHC
59.4
72.4
83.4
66.4
84.8
93.4
72.8
96.6
102.8
kW
12.26
11.82
11.40
12.48
12.06
11.78
12.60
12.20
12.00
