Bryant DURAPAC 551B - Manual (Page 52)

52
PERFORMANCE DATA (cont)
FAN PERFORMANCE — HORIZONTAL DISCHARGE UNITS (cont)
LEGEND NOTE: See page 60 for general fan performance notes.
LEGEND
*Motor drive range: 900 to 1300 rpm. All other rpms require field-supplied drive.
NOTES:
1. Boldface indicates field-supplied drive is required.
2. indicates field-supplied motor and drive are required.
3. Maximum usable watts input is 2120 and maximum continuous bhp is 1.30 for single-
phase units and 2.40 for 3-phase units.
4. See page 60 for general fan performance notes.
LEGEND
*Motor drive range: 1300 to 1685 rpm. All other rpms require field-supplied drive.
NOTES:
1. Boldface indicates field-supplied drive is required.
2. indicates field-supplied motor and drive are required.
3. Maximum continuous bhp is 2.9 and the maximum continuous watts are 2562.
4. See page 60 for general fan performance notes.
558F060 (5 TONS) — STANDARD MOTOR (DIRECT DRIVE)
Airflow
(Cfm)
Low Speed Medium Speed High Speed
208 v 230, 460, 575 v 208 v 230, 460, 575 v 208 v 230, 460, 575 v
ESP Bhp Watts ESP Bhp Watts ESP Bhp Watts ESP Bhp Watts ESP Bhp Watts ESP Bhp Watts
1500 1.01 0.67 750 1.25 0.71 791 1.26 0.70 782 1.46 0.76 845 1.46 0.79 875 1.52 0.85 949
1600 0.82 0.70 780 1.09 0.74 824 1.11 0.74 821 1.32 0.79 883 1.33 0.82 913 1.41 0.89 988
1700 0.64 0.73 810 0.97 0.77 857 0.99 0.77 861 1.22 0.83 921 1.24 0.85 950 1.33 0.92 1027
1800 0.44 0.75 839 0.81 0.80 891 0.84 0.80 900 1.09 0.86 959 1.11 0.89 988 1.22 0.96 1066
1900 0.32 0.78 869 0.66 0.83 924 0.69 0.83 940 0.96 0.90 997 0.99 0.92 1025 1.11 0.99 1105
2000 0.21 0.81 899 0.47 0.86 957 0.51 0.86 979 0.80 0.93 1035 0.83 0.95 1063 0.97 1.03 1144
2100 0.13 0.83 929 0.32 0.89 990 0.36 0.89 1018 0.64 0.96 1073 0.71 0.99 1101 0.86 1.06 1183
2200 0.05 0.86 959 0.19 0.92 1023 0.21 0.92 1058 0.50 1.00 1111 0.58 1.02 1138 0.75 1.10 1222
2300 — — — 0.08 0.95 1057 0.08 0.95 1097 0.34 1.03 1149 0.39 1.06 1176 0.57 1.13 1261
2400 — — — — — — — — — 0.24 1.07 1187 0.29 1.09 1213 0.49 1.17 1300
2500 — — — — — — — — — 0.15 1.10 1225 0.15 1.12 1251 0.34 1.20 1340
Bhp — Brake Horsepower Input to Fan
ESP — External Static Pressure (in. wg)
Watts — Input Watts to Motor
558F060 (5 TONS) — ALTERNATE MOTOR (BELT DRIVE)*
Airflow
(Cfm)
External Static Pressure (in. wg)
0.1 0.2 0.4 0.6 0.8
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
1500 658 0.27 276 722 0.33 337 840 0.46 470 937 0.59 603 1027 0.74 756
1600 693 0.32 327 754 0.38 388 867 0.52 531 963 0.65 664 1052 0.81 828
1700 729 0.38 388 787 0.44 450 895 0.58 593 991 0.73 746 1075 0.88 899
1800 765 0.45 460 821 0.51 521 923 0.65 664 1019 0.81 828 1099 0.96 981
1900 802 0.52 531 854 0.58 593 953 0.73 746 1046 0.90 920 1126 1.06 1083
2000 840 0.60 613 900 0.66 674 984 0.82 838 1073 0.99 1012 1154 1.16 1185
2100 878 0.69 705 923 0.75 766 1015 0.91 930 1101 1.08 1104 1182 1.27 1298
2200 916 0.78 797 958 0.85 869 1046 1.01 1032 1129 1.19 1216 1209 1.39 1420
2300 954 0.89 910 993 0.96 981 1079 1.13 1155 1160 1.31 1339 1237 1.51 1543
2400 993 1.00 1022 1029 1.07 1093 1112 1.25 1277 1190 1.43 1461 1264 1.63 1666
2500 1031 1.13 1155 1066 1.20 1226 1145 1.39 1420 1220 1.57 1604 1292 1.77 1809
558F060 (5 TONS) — ALTERNATE MOTOR (BELT DRIVE)* (cont)
Airflow
(Cfm)
External Static Pressure (in. wg)
1.0 1.2 1.4 1.6 1.8
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
1500 1108 0.90 920 1186 1.08 1104 1263 1.30 1328 1343 1.58 1615 1431 1.79 1829
1600 1130 0.97 991 1205 1.15 1175 1278 1.35 1380 1350 1.61 1645 1424 1.80 1921
1700 1154 1.06 1083 1226 1.23 1257 1296 1.42 1451 1364 1.64 1676 1432 1.89 1931
1800 1178 1.14 1165 1249 1.32 1349 1316 1.52 1553 1382 1.72 1758 1447 1.95 1993
1900 1201 1.23 1257 1274 1.43 1461 1338 1.62 1656 1402 1.80 1870 1464 2.05 2095
2000 1226 1.33 1359 1297 1.53 1564 1363 1.73 1768 1424 1.94 1983 1484 2.16 2207
2100 1252 1.45 1482 1320 1.64 1676 1388 1.80 1891 1448 2.07 2115 1505 2.29 2340
2200 1280 1.58 1615 1345 1.77 1809 1410 1.97 2013 1473 2.20 2248 1529 2.43 2483
2300 1309 1.71 1747 1372 1.91 1952 1434 2.11 2156 1496 2.34 2391 1554 2.58 2637
2400 1336 1.80 1891 1400 2.06 2105 1459 2.26 2310 1519 2.48 2534 1578 2.76 2820
2500 1363 2.00 2044 1428 2.22 2269 1486 2.43 2483 1543 2.65 2708 1600 2.89 2953
Bhp — Brake Horsepower Input to Fan
Watts — Input Watts to Motor
558F060 (5 TONS) — HIGH-STATIC MOTOR (BELT DRIVE)*
Airflow
(Cfm)
External Static Pressure (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
1500 789 0.40 420 896 0.53 557 990 0.67 704 1072 0.83 872 1153 1.00 1051
1600 826 0.46 483 931 0.61 641 1020 0.75 788 1101 0.91 956 1178 1.09 1145
1700 865 0.54 567 966 0.69 725 1051 0.84 883 1133 1.01 1061 1205 1.18 1240
1800 905 0.62 661 1002 0.78 820 1084 0.93 977 1163 1.10 1156 1235 1.29 1355
1900 945 0.72 757 1037 0.88 925 1119 1.04 1093 1194 1.21 1271 1266 1.40 1471
2000 984 0.82 862 1072 0.98 1030 1154 1.16 1219 1226 1.33 1397 1297 1.53 1608
2100 1024 0.93 977 1108 1.10 1156 1192 1.29 1355 1259 1.47 1545 1327 1.66 1744
2200 1064 1.05 1103 1145 1.22 1282 1225 1.43 1503 1294 1.62 1702 1359 1.80 1902
2300 1104 1.18 1240 1183 1.36 1429 1260 1.57 1650 1330 1.78 1870 1392 1.97 2070
2400 1145 1.32 1387 1222 1.45 1524 1296 1.73 1818 1365 1.94 2038 1426 2.15 2259
2500 1186 1.48 1555 1262 1.68 1765 1331 1.89 1986 1400 2.12 2227 1461 2.34 2459
558F060 (5 TONS) — HIGH-STATIC MOTOR (BELT DRIVE)* (cont)
Airflow
(Cfm)
External Static Pressure (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts Rpm Bhp Watts
1500 1221 1.17 1229 1256 1.30 1366 1283 1.32 1387 1303 1.22 1282 1345 1.34 1390
1600 1252 1.27 1334 1311 1.45 1524 1340 1.58 1660 1330 1.61 1692 1373 1.77 1834
1700 1278 1.37 1439 1345 1.57 1650 1397 1.76 1849 1424 1.89 1986 1470 2.08 2153
1800 1303 1.48 1555 1371 1.69 1776 1433 1.90 1996 1480 2.09 2196 1528 2.30 2381
1900 1330 1.59 1671 1396 1.80 1902 1460 2.03 2133 1517 2.25 2364 1566 2.47 2563
2000 1362 1.73 1818 1422 1.94 2038 1485 2.16 2270 1544 2.40 2522 1594 2.64 2734
2100 1393 1.87 1965 1452 2.08 2185 1510 2.31 2427 1570 2.55 2674 1620 2.80 2905
2200 1423 2.02 2122 1483 2.24 2354 1538 2.46 2585 1594 2.71 2821 1645 2.98 3087
2300 1454 2.18 2291 1515 2.41 2532 1571 2.64 2758 1623 2.88 2976 1675 3.17 3280
2400 1485 2.36 2480 1544 2.59 2721 1604 2.84 2947 1657 3.07 3152 1710 3.38 3497
2500 1518 2.55 2679 1574 2.78 2905 1633 3.03 3134 1692 3.28 3345 1746 3.61 3736
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
Watts — Input Watts to Motor
