Form # 147459 Issue 11/06 Web Rev_01 55
OPERATION
Transporting the Windrower
TOWING WINDROWER WITHOUT TRAILER
(continued)
WARNING: When towing the
windrower without a trailer:
3. Lock casters in a straight-ahead or straight-
back position with L-pin (F). Secure L-pin
with hairpin in lock or storage position. (See
storage position, lower right photo on page
52.)
4. Be sure the towing vehicle is heavier than
the windrower.
NOTE: Windrower weighs 8000 to 10000 lbs.
(3600 to 4500 kg) depending on header size.
Remember stopping distance increases
when towing, especially on hills and slopes.
5. Do not exceed 16 mph (26 km/h) when
towing windrower.
6. Remember that when towing windrower
backwards, slow moving vehicle emblem,
reflectors and warning lights are not easily
visible. It is your responsibility to
adequately mark the load when transporting
in this fashion.
7. Set light switch to FLASHER position to
activate amber lamps.
8. Do not tow the windrower on a roadway at
night, or in conditions which reduce
visibility, such as fog or rain. The width of
the load makes it unsafe to transport under
these conditions.
9.
Be aware of roadside obstructions,
oncoming traffic and bridges. Take care
when travelling over rough terrain or on
slopes.
10. IMPORTANT: Before towing, plug or cover
muffler exhaust to prevent the turbine from
turning without lubrication. This "free-wheeling"
of the turbocharger can cause damage.
CASTER TRANSPORT LOCK
F
