Form # 147459 Issue 11/06 Web Rev_01 128
TROUBLE SHOOTING
SYMPTOM
PROBLEM SOLUTION REF
Header Drive (continued)
Belt band frayed and
separated from V-belt at
one side. Belt has jumped one
groove at front pulley:
Belt shield too far from
pulley.
Belt guides and shields
not properly adjusted.
Adjust pulley shield.
Adjust belt guides and
keepers
95
95
Belt bands or sides of
belt prematurely worn.
Burnt paint on shields or
guides. Belt guides and keepers
too close to belt. Adjust belt guides and
keepers. 95
Park Brake
Loss of brake capacity.
Worn Brake Discs *
Brake solenoid not
energising *
*
Incomplete brake
release. Brake not releasing fully Press min.(200psi) on
brake release valve
(Traction Charge). *
Operator's Seat
Rough ride.
Seat suspension not
adjusted for operator's
weight. Adjust seat suspension. 26
High air pressure in
tires. Deflate to proper
pressure. 12
* See your Windrower dealer.
