Form # 147459 Issue 11/06 Web Rev_01 129
OPTIONS AND ATTACHMENTS
Consult your Windrower dealer for details on the
following Options & Attachments.
NOTE: If not factory ordered, installation of these
kits is to be done by Windrower dealer.
Air Intake Screen Cleaner
WholeGoods order number: B2972
This automatic screen cleaning device "vacuums"
the screen by means of two rotors.
In-Frame Rear Weight Package
WholeGoods order number: B2266
For heavier headers (3000 lbs. plus, including reel)
in hilly conditions, weight may be added to rear of
tractor frame. One or two weight packs may be
installed, as described on page 44. NOTE: For
high clearance tractors (9352/4952/2952/8152)
two of these weight packs are factory installed.
If additional weight is required after installation of
two in-frame weight packs, behind-frame packages
are available as below:
Behind-Frame Weight Packages
400 lb. (181 kg) Package: WholeGoods order
number: B2980
Additional 300 lb. (136 kg) Package:
WholeGoods order number: B2981 (requires 400
lb. package be installed)
Header “Express-Down” Module
WholeGoods order number: B2964
Allows the header lift cylinders to completely
retract and lower the header with only momentary
activation of the header height control switch. Also
includes feature by-pass switch. Installation
instructions are included with the kit.
Formed Tail-Wheel Casters
Tractor Models 9352c, 4952c, 2952c, 8152c:
WholeGoods order number: B2998 – 7.5-16 tires
Auxiliary Float Spring Kit
WholeGoods order number: B2773
Required to provide adequate float for heavier
headers in windrowing applications.
NOTE: 36’ Double Sickle headers require four
auxiliary float spring kits. See the Windrower
Tractor Parts Catalog for service components of
kit.
Forked Tail-Wheel Casters
Tractor Models 9352c, 4952c, 2952c, 8152c:
WholeGoods order number: B2995 – 11-16 tires
B2996 – 16.5L-16.1 tires
Hydraulic Reel Fore-Aft Module
WholeGoods order numbers: B2960 – Base Kit*
B2961 – Fore-Aft
Provides hydraulic components and controls
required to accept headers with reel fore-aft
option, which allows in-cab adjustment of reel fore-
aft position. Installation instructions are provided
with the kit.
* - One Base Kit B2960 is required for either, or
both the Hydraulic Reel Fore-Aft Module and the
Hydraulic Header Tilt Module. (If both options are
installed, only one base kit is required.)
Hydraulic Header Tilt Module
WholeGoods order numbers: B2960 – Base Kit*
B2962 – Header Tilt
The mechanical center link to the header is
replaced with a hydraulic cylinder to allow in-cab
adjustment of header tilt (angle) by means of a
switch on the ground speed control handle.
Shallow Angle Kit
WholeGoods order numbers: B4482
Modifies tractor lift linkage to permit shallower
header angle for rocky field conditions to prevent
cutterbar damage.
AIR INTAKE SCREEN CLEANER FORKED CASTER OPTION
Approved Radio Source:
REI (Radio Engineering Industries, Inc.)
Omaha, Nebraska
Ph. 1-800-228-9275
