Form # 147459 Issue 11/06 Web Rev_01 12
SPECIFICATIONS
TRANSMISSION:
Type ............................................................................................................................................ Hydrostatic
Displacement..................................................................................................................3.0 cu.in. (49.16 cc)
Fluid......................................................See "Fuels, Fluids and Lubricants" in Maintenance/Service section
FINAL DRIVE:
Type .............................................................................................................................Planetary Gear Drive
Ratio: ............................................................................................................................................. 37.68 to 1
Lubricant...............................................See "Fuels, Fluids and Lubricants" in Maintenance/Service section
SPEED RANGE:
Dual Speed Forward.: ...................................... Field: 0 - 9 mph (14.5 km/h) Road: 0 – 15.5 mph (25 km/h)
Reverse .......................................................................................................................... 0 - 6 mph (10 km/h)
HEADER DRIVE:
Mechanical ............................................................................ 4-A section belt, electric over hydraulic clutch
Hydraulic ............................. 2 circuits, clutch activated, w/ independent flow controls (3 - 9 US gpm each)
CYLINDER CONTROL VALVE: Type .....................................................Cartridge valves in manifold block
ELECTRICAL:
Battery Requirement .................................................................. 12 Volt, minimum 640 CCA @ 0
°F (-18°C)
Alternator......................................................................................................................................... 110 Amp
Breakers:
Lights (manual re-set)....................................................................................................... 50 Amp
Main (all functions except lights, manual re-set) .............................................................. 50 Amp
Air Conditioning and Seat Suspension Switch ................................................................. 25 Amp
Header Controls, Operator Presence System .................................................................. 10 Amp
Instruments, Radio and Screen Motors .............................................................................. 6 Amp
Wiper, Interior Light, Radio Memory and Auxiliary Power Points ....................................... 6 Amp
Fuse: Cigar Lighter ..................................................................................................................... 20 Amp
AIR CONDITIONING:
Cooling Capacity ............................................................................................................. 24,000 B.T.U./hour
Compressor..................................................................................................................9.5 cu. in./rev., rotary
BRAKES: .......................... Hydraulic, integral disc brakes – engaged when transmission locked in neutral
DRIVE TIRES:
14.9 – 24 R4 Bar Tread – Sprayer Application Only
560 – 65D24 Softrac II Turf Tread
500 – 70R24 Radial - Bar Tread
540 – 65R24 Radial – Deep Bar Tread
NOTE: Pressures below are for a fully loaded header. If hay conditioner is removed, or a bat reel replaces a
pick-up reel, reduce pressures by 2 psi (14 kPa).
Drive Tire Inflation Pressures
Header Model Header Size 14.9 - 24 500 - 70R24 540- 65R24 or 560-65D24
912, 922, 933 All 33 psi (228 kPa) 19 psi (132kPa) 18 psi (125 kPa)
962 All 36 psi (248 kPa) 21 psi (145 kPa) 20 psi (138 kPa)
972 12 - 21 33 psi (228 kPa) 19 psi (132kPa) 18 psi (125 kPa)
972/Sprayer 25 - 36 42 psi (289 kPa) 24 psi (165 kPa) 22 psi (151 kPa)
TAIL WHEEL TIRES: Inflation Pressure
16.5L - 16.1 I1 8 ply Rib Implement .. 10 psi (70 kPa)
11 – 16 F-2M 8 Ply Rib Implement..... 10 psi (70 kPa)
7.5 – 16 6 ply Single Rib TT, F-1...... 19 psi (132 kPa)
CAPACITIES: See "System Capacities" in Maintenance/Service section.
