3-21
3.2.14. Network and Dial-up Connections
ICON ITEM & FUNCTION
“Connection” Tab
(Figure 3-45 to Figure 3-55)
To create a “Dial-up Connection”:
• Double-tap the “Make New connection”.
• In the “Make New Connection” dialog box, enter a name for the connection.
• Select
“Dial-Up Connection”.
• Select the “Next” button.
• Select the modem you want use.
• Select “Configure”
• Under “Connection Reference”, use the default settings provided. If you can’t
connect using these settings, see your ISP or network administrator for specific
information. If you want to always enter a phone number before connecting,
Select “Manual Dial”. Select “OK”.
• Select “TCP/IP Settings”. In the “General” tab, ensure “Use Server-assigned IP
address” is selected. In the “Name Servers” tab, ensure “Use Server-assigned
addresses” is selected, and select “OK”. If you are unable to connect with these
default settings, see your ISP or network administrator for specific TCP/IP
information.
• Select the “Next” button and type the telephone number.
• Select the “Finish” button.
The connection you just created appears as an icon in the “Network and Dial-up
Connections” folder.
• Set up a point-to-Point Protocol (PPP) account with an ISP and obtain the
following information:
o Access telephone number
o User
name
o Password
• Once you have established an account, create a new connection on your device.
When creating this connection, you should be able to use all of the default TCP/IP
settings provided in the Make New Connection Wizard. If you can’t connect using
the default settings, contact your ISP or access your ISP’s Web site for specific
TCP/IP information as well as primary and secondary DNS address.
Modify Connection Setting
• Select Start > Settings > Network and Dialup Connections
• Select the icon for connection settings you want to modify.
• Select File > Properties, or double- tap the appropriate icon.
• Select desired options. There may be additional settings that depend on the
connection. To modify, select the icon and select the icon and select Advanced
Settings… from the menu.
