Opticon ESL - Manual (Page 7)

Opticon ESL
DEMO KIT
User Manual
7
1.4. Environmental Specifications
1.4.1. Operating Temperature and Humidity (EE200)
Temperature: 0 to 50° C
Humidity: 0-85%
1.4.2. Storage Temperature and Humidity (EE200)
Temperature: -20 to 60° C
Humidity: 0-85%
1.5. Interface Specifications
The radio interface of both the base stations and ESLs have the following
specifications:

2.4gHz IEEE 802.15.4 compatible

Transmission speeds: up to 250 kbps
1.6. Hardware Specifications
Items Specifications Remarks
CPU
Type
CC2530-F128 (EE200)
CC2530-F256 (EBS-10)
Internal ROM
256 KB (EBS-10)
128 KB (EE200)
Internal RAM 8 KB
Clock frequency 32 MHz
Display
(EE200)
Active area W 45 x H 22 mm
Number of dots W 200 x H 96
Model EG020AS183
Gray scale level 1 bit Black and white
Contrast ratio 10:1
Pixel pitch 111 dpi
Connector
(EBS-10)
Ethernet 10/100 Mbit
Radio
Frequency 2.4gHz
Protocol IEEE 802.15.4
