A.2.4. Images
An image (fixed or dynamic) can be added to the template using the following format:
%4% Templates\images\G%4%.bmp 173 33
%4%
173
33

(optional) Displaying conditions

Image file path (absolute or relative to working directory)

Coordinates of the upper-left corner of the image
A.2.5. Barcodes
Almost any type of barcode can be added to the template using the following format:
%4% %4% 0 5 50 80 100 20 CENTER BOTTOM
%4%
%4%
0
5
50
80
100
20
CENTER
BOTTOM

(optional) Displaying conditions

Content of the barcode

Foreground Color (0=Black; 1=White)

Specifies the bar code type (See list below)

Specify the rectangle within the barcode is rendered

Horizontal alignment (LEFT, CENTER or RIGHT)

Vertical alignment (TOP, BOTTOM)
The barcode type can be one of the following values:
1. UPC-A
2. UPC-E
3. UPC 2 Addon/supplemental chars
4. UPC 5 Addon/supplemental chars
5. EAN-13
