A.2.2. Rectangles
A (filled) rectangle can be added to the template using the following format:
%6% 0 0 0 200 32
%6%
0
0
0
200
32

(optional) Displaying conditions

Color (0=Black; 1=White)

Specify the position and size of the rectangle
A non-filled rectangle can be added by simply drawing two rectangles on top of each other
in opposite colors.
A.2.3. Lines
A line can be added to the template using the following format:
%6% 0 0 77 200 77 1
%6%
0
0
77
200
77
1

(optional) Displaying conditions

Color (0=Black; 1=White)

Specify start/end coordinates

Thickness of the line
